Receiver sensitivity: 2.4GHz:
802.11n (20MHZ): -70 dBm
802.11n (40MHZ): -68 dBm
802.11g: -72 dBm
802.11b: -95 dBm
5GHz:
802.11ac (80MHZ): -62 dBm
802.11ac (40MHZ): -65 dBm
802.11ac (20MHZ): -68 dBm
802.11n (40MHZ): -68 dBm
802.11n (20MHZ): -70 dBm
802.11a: -72 dBm
Features
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
2.4 GHz: Yes
Frequency band: 2.4 - 5.825 GHz
Networking standards: IEEE 802.3u, IEEE 802.11ac, IEEE 802.3, IEEE 802.11a, IEEE 802.11i, IEEE 802.11b, IEEE 802.3af, IEEE 802.3x, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n
Number of users: 80 user(s)
5 GHz: Yes
Modulation: 16-QAM, BPSK, DQPSK, CCK, QPSK, 64-QAM, DSSS, OFDM, DBPSK
Maximum data transfer rate: 433 Mbit/s
Flow control support: Yes
Wi-Fi Multimedia (WMM)/(WME): Yes
Quality of Service (QoS) support: Yes
Channels quantity: 36 channels
Automatic channel selection: Yes
Design
Reset button: Yes
Product colour: White
Placement: Ceiling, Wall
LED indicators: Power, WLAN
Internal: No
Power
Output voltage: 12 V
Power over Ethernet (PoE): Yes
Power consumption (typical): 15 W
Output current: 1.5 A
Security
Service Set Identifier (SSID) features: SSID broadcast on/off
Security algorithms: 64-bit WEP, WPA2, WPA2-AES, WPA, 128-bit WEP, WPA2-TKIP, WPA2-PSK
Number of SSID supported: 8
Operational conditions
Operating temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): -20 - 50%
Storage temperature (T-T): 5 - 90 °C
Storage relative humidity (H-H): 10 - 90%
Management features
Firmware upgradeable: Yes
Web-based management: Yes
Switch type: Managed
Weight & dimensions
Weight: 326 g
Depth: 38.5 mm
Height: 189 mm
Width: 189 mm
Packaging data
Package weight: 680 g
Package depth: 62 mm
Package width: 214 mm
Package height: 317 mm
Packaging content
Quick start guide: Yes
Cables included: LAN (RJ-45)
Ports & interfaces
DC-in jack: Yes
WAN connection: Wi-Fi, Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports: 2
Antenna
Antennas quantity: 3
Antenna features: Integrated antenna
Antenna direction type: Omni-directional
Antenna gain level (max): 15 dBi
Logistics data
Harmonized System (HS) code: 85176990
