Technical details
Pallet net width: 120 cm
Pallet net length: 80 cm
Master (outer) cases per pallet (air): 24 pc(s)
Pallet net height: 164 cm
Features
Cabling technology: 10/100/1000Base-T(X)
Channels quantity: 165 channels
Maximum outdoor range: 5000 m
MIMO type: Multi User MIMO
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
MIMO: Yes
Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.3at, IEEE 802.3af, IEEE 802.11n
2.4 GHz: No
Frequency band: 4.92 - 5.92 GHz
Maximum data transfer rate: 867 Mbit/s
5 GHz: Yes
Design
International Protection (IP) code: IP65
Placement: Pole
Product colour: White
LED indicators: System, WAN, LAN
Power
Input current: 1.5 A
AC input voltage: 12 V
Power over Ethernet (PoE): Yes
Security
Number of SSID supported: 4
Security algorithms: WEP, WPA, WPA2
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -30 - 45 °C
Storage temperature (T-T): -40 - 75 °C
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Depth: 257 mm
Height: 45 mm
Width: 87 mm
Weight: 440 g
Performance
Internal memory: 128 MB
Processor manufacturer: Qualcomm
Flash memory: 16 MB
Built-in processor: Yes
Internal memory type: DDR2
Packaging data
Package weight: 660 g
Package height: 95 mm
Package width: 106 mm
Package depth: 332 mm
Packaging content
Quick start guide: Yes
Mounting kit: Yes
Cables included: LAN (RJ-45)
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
WAN connection: Ethernet (RJ-45)
DC-in jack: Yes
Antenna
Antennas quantity: 1
Antenna type: Internal
Antenna gain level (max): 14 dBi
Logistics data
Master (outer) case gross weight: 15 kg
Master (outer) case length: 495 mm
Master (outer) case height: 455 mm
Products per master (outer) case: 20 pc(s)
Harmonized System (HS) code: 85176990
Master (outer) case width: 350 mm
Country of origin: China
