Technical details
Pallet net length: 80 cm
Pallet net width: 120 cm
Master (outer) cases per pallet (air): 10 pc(s)
Pallet net height: 164.4 cm
Features
2.4 GHz: Yes
Frequency band: 2.412 - 2.484, 5.18G -5.825
MIMO: Yes
Maximum data transfer rate: 1800 Mbit/s
5 GHz: Yes
Channels quantity: 165 channels
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Operating modes: Gateway, Repeater, AP
MIMO type: Multi User MIMO
Maximum data transfer rate (5 GHz): 1201 Mbit/s
6 GHz: No
Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3ab, IEEE 802.11ax
Spread spectrum method: OFDMA
Design
Product colour: White
Placement: Ceiling, Wall
LED indicators: Status
Power
Power consumption (max): 14 W
Power over Ethernet (PoE): Yes
Security
Service Set Identifier (SSID) features: Multiple SSIDs
Number of SSID supported: 8
Security algorithms: AES, WPA2, WPA, WPA3
Operational conditions
Storage relative humidity (H-H): 5 - 90%
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): 0 - 70 °C
Operating temperature (T-T): 0 - 55 °C
Management features
Web-based management: Yes
Weight & dimensions
Depth: 186 mm
Height: 42.5 mm
Width: 186 mm
Weight: 418.5 g
Performance
Internal memory: 512 MB
Flash memory: 128 MB
Chipset: Qualcomm IPQ6000
Packaging data
Package height: 76 mm
Package width: 243 mm
Package depth: 235 mm
Package weight: 750 g
Packaging content
Cables included: LAN (RJ-45)
Quick start guide: Yes
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 2
Antenna
Antenna type: Internal
Antenna gain level (max): 4 dBi
Antennas quantity: 4
Logistics data
Country of origin: China
Products per master (outer) case: 20 pc(s)
Master (outer) case length: 520 mm
Master (outer) case height: 500 mm
Master (outer) case gross weight: 16 kg
Master (outer) case width: 410 mm
Sustainability
Sustainability compliance: Yes
