Receiver sensitivity: 2.4 GHz Radio : l 802.11b / 1Mbps / RX Sensitivity : -90
(dBm) l 802.11b / 11Mbps / RX Sensitivity : -85 (dBm) l
802.11g / 6Mbps / RX Sensitivity : -90 (dBm) l 802.11g /
54Mbps / RX Sensitivity : -72 (dBm) l 802.11n HT20 /
MCS0 / RX Sensitivity : -87 (dBm) l 802.11n HT20 / MCS7
/ RX Sensitivity : -70 (dBm) l 802.11n HT40 / MCS0 / RX
Sensitivity : -85 (dBm) l 802.11n HT40 / MCS7 / RX
Sensitivity : -68 (dBm) l 802.11ax HE20 / MCS0 / RX
Sensitivity : -83 (dBm) l 802.11ax HE20 / MCS11 / RX
Sensitivity : -60 (dBm) l 802.11ax HE40 / MCS0 / RX
Sensitivity : -83 (dBm) l 802.11ax HE40 / MCS11 / RX
Sensitivity : -56 (dBm) 5 GHz Radio : l 802.11a HT20 /
6Mbps/ RX Sensitivity : -92 (dBm) l 802.11a HT20 /
54Mbps/ RX Sensitivity : -72 (dBm) l 802.11n HT20 /
MCS0 / RX Sensitivity : -90 (dBm) l 802.11n HT20 / MCS7
/ RX Sensitivity : -70 (dBm) l 802.11n HT40 / MCS0 / RX
Sensitivity : -88 (dBm) l 802.11n HT40 / MCS7 / RX
Sensitivity : -68 (dBm) l 802.11ac VHT20 / MCS0 / RX
Sensitivity : -88 (dBm) l 802.11ac VHT20 / MCS8 / RX
Sensitivity : -70 (dBm) l 802.11ac VHT40 / MCS0 / RX
Sensitivity : -88 (dBm) l 802.11ac VHT40 / MCS7 / RX
Sensitivity : -68 (dBm) l 802.11ac VHT80 / MCS0 / RX
Sensitivity : -85 (dBm) l 802.11ac VHT80 / MCS9 / RX
Sensitivity : -58 (dBm) l 802.11ax HE20 / MCS0 / RX
Sensitivity : -88 (dBm) l 802.11ax HE20 / MCS11 / RX
Sensitivity : -62 (dBm) l 802.11ax HE40 / MCS0 / RX
Sensitivity : -86 (dBm) l 802.11ax HE40 / MCS11 / RX
Sensitivity : -58 (dBm) l 802.11ax HE80 / MCS0 / RX
Sensitivity : -84 (dBm) l 802.11ax HE80 / MCS11 / RX
Sensitivity : -55 (dBm) l 802.11ax HE160 / MCS0 / RX
Sensitivity : -82 (dBm) l 802.11ax HE160 / MCS11 / RX
Sensitivity : -51 (dBm)
Features
Spread spectrum method: OFDMA
MIMO: Yes
Ethernet LAN data rates: 100, 1000 Mbit/s, 10
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3at
2.4 GHz: Yes
5 GHz: Yes
Maximum data transfer rate: 3000 Mbit/s
6 GHz: No
Channels quantity: 165 channels
Maximum data transfer rate (5 GHz): 2401 Mbit/s
Cabling technology: 10/100/1000Base-T(X)
Maximum outdoor range: 100 m
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
MIMO type: Multi User MIMO
Design
Product colour: White
LED indicators: Status, System, Power
International Protection (IP) code: IP67
Placement: Pole
Power
Power consumption (typical): 16 W
Power over Ethernet (PoE): Yes
Security
Security algorithms: WPA3, WPA2
Number of SSID supported: 8
Operational conditions
Storage temperature (T-T): -20 - 80 °C
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -20 - 50 °C
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Weight: 1.3 kg
Width: 230 mm
Depth: 107 mm
Height: 38 mm
Performance
Flash memory: 128 MB
Internal memory: 512 MB
Packaging data
Package width: 380 mm
Package depth: 230 mm
Package type: Box
Package weight: 1.73 kg
Package height: 107 mm
Packaging content
Mounting kit: Yes
Quick start guide: Yes
Quantity per pack: 1 pc(s)
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
WAN connection: Wi-Fi
Ethernet LAN (RJ-45) ports: 1
Antenna
Antenna type: Internal
Antenna direction type: Omni-directional
Other features
Wireless standard: IEEE 802.11a/b/g/n/ac/ax
Logistics data
Country of origin: China
