Certification: CE
Technical details
Video compression formats: H.264, MP4
Remote viewing: Yes
Pallet net length: 80 cm
Supported video modes: 720p
Pallet net width: 140 cm
Pallet net height: 120 cm
Country of origin: China
Web-based management: Yes
Product colour: White, Black
Power
Recorder power consumption (typical): 8 W
Camera power consumption (standby): 4 W
DC output voltage: 12
Power source type: DC
Operational conditions
Operating temperature (T-T): -40 - 80 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Camera width: 6.4 cm
Recorder width: 22 cm
Camera height: 6.4 cm
Recorder height: 4.5 cm
Recorder depth: 22.2 cm
Camera depth: 16.5 cm
Depth: 430 mm
Height: 221 mm
Width: 225 mm
Network
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
System requirements
Mobile operating systems supported: Android, iOS
Packaging data
Package depth: 154 mm
Package height: 308 mm
Package width: 374 mm
Package weight: 4 kg
Packaging content
Software CD: Yes
Power supply included: Yes
Package type: Box
Manual: Yes
Quick installation guide: Yes
Cables included: DC
Audio
Audio formats supported: G.711 A-law
Built-in microphone: No
Camera
Placement supported: Indoor/outdoor
Sensor type: CMOS
Camera included: Yes
Camera cable length: 18 m
Camera interface: BNC
Viewing angle: 65°
Surveillance camera form factor: Bullet
Heat function: No
Rotating: No
Night mode: Yes
International Protection (IP) code: IP66
Camera shutter speed: 1/50 - 1/100000 s
LED type: IR
Number of cameras: 4
Night vision distance: 30 m
Optical sensor size: 25.4 / 4 mm (1 / 4")
Connectivity technology: Wired
Playback resolutions supported: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Recorder
HDD size: 3.5"
BNC input ports: 8
Maximum HDD capacity: 6 TB
Recorder included: Yes
Storage media type: HDD
HDD capacity: 6 TB
Channels quantity: 8 channels
Line inputs (RCA): 1
Line outputs (RCA): 1
Optical drive included: No
Supported network protocols: TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP, HTTPS
Operating system installed: Linux Embedded
Number of HDDs supported: 1
VGA (D-Sub) ports quantity: 1
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
LED indicators: Power, HDD, LAN
Card reader integrated: No
USB 2.0 ports quantity: 2
