Design
Product colour: Black
Stackable: No
Rack mounting: No
LED indicators: Link, Power, Activity, PoE
Power
Power source: AC
AC input voltage: 100 - 240 V
Power consumption (typical): 5 W
Operational conditions
Operating relative humidity (H-H): 5 - 90%
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 75 °C
Operating temperature (T-T): -10 - 55 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Weight: 790 g
Depth: 150 mm
Height: 35 mm
Width: 210 mm
Network
10G support: No
Half duplex: Yes
Ethernet LAN data rates: 100,1000 Mbit/s
Networking standards: IEEE 802.3u, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3i
Full duplex: Yes
Auto-negotiation: Yes
VLAN support: Yes
Performance
Fanless: Yes
Mean time between failures (MTBF): 5000 h
Packaging data
Package width: 264 mm
Package weight: 1.14 kg
Package depth: 217 mm
Package height: 67 mm
Packaging content
Quick start guide: Yes
Cables included: AC
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 10
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Fast Ethernet (copper) ports quantity: 8
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: China
Data transmission
MAC address table: 2000 entries
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 120 W
Power over Ethernet (PoE): Yes
