Technical details
Number of video streams: 2
Design
Form factor: Dome
Mounting type: Ceiling/Desk
Country of origin: Taiwan
Product colour: White, Black
LED indicators: Link, Power
Power
Power over Ethernet (PoE): Yes
Power consumption (typical): 6 W
DC output current: 1.5 A
Power source type: PoE
AC input voltage: 24 V
Security
Motion sensor: Yes
HTTPS encryption: Yes
IP address filtering: Yes
Password protection type: User
Operational conditions
Operating relative humidity (H-H): 10 - 80%
Operating temperature (T-T): 0 - 40 °C
Management features
Reset button: Yes
Weight & dimensions
Height: 93 mm
Width: 63 mm
Depth: 63 mm
Weight: 380 g
Network
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Supported network protocols: TCP/IP, HTTP, SMTP, FTP, DDNS, UPnP, NTP, PPPoE, DNS, DHCP, RTSP, Samba
Wi-Fi: No
Networking standards: IEEE 802.3af, IEEE 802.3, IEEE 802.3u
System requirements
Windows operating systems supported: Windows Vista Business x64, Windows Vista Business, Windows Vista Ultimate, Windows Vista Home Basic x64, Windows Vista Home Basic, Windows Vista Home Premium, Windows XP Home, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Ultimate x64, Windows Vista Home Premium x64, Windows 7 Professional, Windows 8, Windows 7 Home Premium, Windows 7 Starter, Windows 7 Home Basic x64, Windows 7 Professional x64, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows XP Professional, Windows 7 Starter x64, Windows XP Professional x64, Windows 7 Ultimate x64, Windows 7 Home Basic, Windows 7 Ultimate, Windows 7 Enterprise, Windows XP Home x64
Certification: CE, FCC, Onvif
Performance
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Placement supported: Indoor & outdoor
Day/night mode: Yes
PTZ control: Yes
Connectivity technology: Wired
Packaging data
Package weight: 700 g
Package width: 205 mm
Package depth: 155 mm
Package height: 90 mm
Package type: Box
Packaging content
AC adapter included: Yes
Mounting kit: Yes
Manual: Yes
Quick installation guide: Yes
Screws included: Yes
Audio
Audio system: 1-way
Voice codecs: AMR
Built-in microphone: Yes
Storage
Compatible memory cards: MicroSDHC, MicroSD (TransFlash)
Card reader integrated: Yes
Maximum memory card size: 64 GB
Built-in HDD: No
Ports & interfaces
Interface: RJ-45
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Camera
Minimum illumination: 1 lx
White balance: Auto
Camera shutter type: Electronic
Camera shutter speed: 1/30 - 1/1000000 s
Logistics data
Harmonized System (HS) code: 85258900
Image sensor
Sensor type: CMOS
Progressive scan: Yes
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Video
Full HD: Yes
Flip & mirror: Yes
Image quality adjustment: Saturation, Sharpness, Contrast, Brightness
Video formats supported: MPEG4
Automatic gain control: Yes
Video compression formats: H.264, MPEG4, M-JPEG
Time stamp overlay: Yes
Supported video modes: 720p, 240p, 480p, 1080p
Total megapixels: 2 MP
Noise reduction: Yes
Supported graphics resolutions: 640 x 480 (VGA), 1920 x 1080 (HD 1080), 320 x 240, 1280 x 720 (HD 720)
Maximum resolution: 1920 x 1080 pixels
Frame rate: 30 fps
Night vision
Night vision distance: 10 m
Number of illumination LEDs: 19
LED type: IR
Night vision: Yes
Lens system
Zoom capability: Yes
Fixed focal length: 4 mm
Focus adjustment: 2.0
Sustainability
Compliance certificates: RoHS
