Design
Stackable: No
LED indicators: Activity, Link, Power
Rack mounting: Yes
Form factor: 1U
Product colour: Black
Power
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power source: AC
Security
Authentication type: RADIUS
IGMP snooping: Yes
Access Control List (ACL): Yes
IP-MAC-Port binding: Yes
Authentication: MAC-based authentication, Port-based authentication
SSH/SSL support: Yes
DHCP features: DHCP snooping, DHCP client
Operational conditions
Heat dissipation: 136.48 BTU/h
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 50 °C
Management features
ARP inspection: Yes
Switch type: Managed
Switch layer: L2+
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 440 mm
Height: 44 mm
Weight: 2.77 kg
Depth: 245 mm
Network
Copper ethernet cabling technology: 10BASE-T, 1000BASE-T, 100BASE-TX
Port mirroring: Yes
Policy-based routing: Yes
Virtual LAN features: Port-based VLAN, Tagged VLAN, Protocol-based VLAN, Private VLAN
Spanning tree protocol: Yes
10G support: No
QinQ implementation: Flexible QinQ, QinQ, Basic QinQ
Ethernet LAN data rates: 1000 Mbit/s
VLAN support: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3u, IEEE 802.1w, IEEE 802.1D, IEEE 802.3z
Performance
Telnet: Yes
Mean time between failures (MTBF): 534.057 h
Fanless: No
Firmware upgradeable: Yes
Internal memory: 256 MB
Flash memory: 512 MB
Noise level: 45 dB
Packaging data
Rack rails: Yes
Package height: 95 mm
Package width: 525 mm
Package type: Box
Package depth: 390 mm
Package weight: 3.7 kg
Packaging content
Quick start guide: Yes
Cables included: AC
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 24
SFP module slots quantity: 4
Power connector: AC-in jack
Gigabit Ethernet (copper) ports quantity: 24
Logistics data
Country of origin: China
Data transmission
Static route: Yes
Packet buffer memory: 12 MB
MAC address table: 16000 entries
Jumbo frames support: Yes
Switching capacity: 1000 Gbit/s
Jumbo frames: 10000
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Optical fiber
Fiber ethernet cabling technology: 1000BASE-SX, 1000BASE-LX, 1000BASE-ZX, 1000BASE-LHX
Switching optical modules type: Gigabit Ethernet
