Technical details
Compliance certificates: RoHS
Certification: CE, FCC, ISO9001, ISO14001
Features
On/off switch: Yes
LED indicators: Power, HDD
Country of origin: China
Product colour: Black
Power
Power consumption (typical): 65 W
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Package depth: 290 mm
Height: 315 mm
Package height: 85 mm
Width: 240 mm
Depth: 48 mm
Package width: 485 mm
Package weight: 1.15 kg
Package type: Box
Weight: 1 kg
System requirements
Browser supported: Internet Explorer 9+
Mobile operating systems supported: Android, iOS
Performance
Video input channels: 4 channels
Operating system installed: Embedded LINUX
Throughput data rate: 80 Mbit/s
Video formats supported: MPEG4, H.265, H.264
Number of users: 32 user(s)
Maximum resolution: 3840 x 2160 pixels
Packaging content
CD manual: Yes
Cables included: AC
AC adapter included: Yes
Ports & interfaces
Supported network protocols: TCP,UDP,IPv4,IPv6,Http,Https,SMTP,NTP,SNTP
HDMI ports quantity: 1
HDMI output: Yes
Audio RCA outputs: 1
Audio RCA inputs: 1
Power over Ethernet (PoE) ports quantity: 4
VGA (D-Sub) output ports: 1
USB 2.0 ports quantity: 2
Networking standards: IEEE 802.3at
Ethernet LAN (RJ-45) ports: 4
Power over Ethernet (PoE): Yes
Logistics data
Master (outer) case length: 503 mm
Master (outer) case gross weight: 12.8 kg
Master (outer) case height: 313 mm
Master (outer) case width: 723 mm
Products per master (outer) case: 8 pc(s)
Hard drive
Number of HDDs supported: 1
Maximum storage capacity: 6 TB
HDD capacity: 0 GB
HDD size: 3.5"
