Certification: CE, FCC, ISO9001, ISO14001, uL
Features
Product colour: Black
On/off switch: Yes
Rack mounting: Yes
LED indicators: Power, Alarm, HDD
Country of origin: China
Power
AC input voltage: 100 - 230 V
Power consumption (typical): 180 W
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Package depth: 450 mm
Width: 315 mm
Package type: Box
Package height: 387 mm
Package weight: 3.23 kg
Height: 385 mm
Weight: 3 kg
Depth: 52 mm
Package width: 435 mm
System requirements
Browser supported: Internet Explorer 9+
Performance
Video formats supported: MPEG4, H.265, H.264+, H.264
Operating system installed: Embedded LINUX
Number of fans: 1 fan(s)
Maximum resolution: 3840 x 2160 pixels
Video recording modes: 1080p, 720p
Video input channels: 8 channels
Throughput data rate: 160 Mbit/s
Number of users: 64 user(s)
Packaging content
Cables included: AC
AC adapter included: Yes
CD manual: Yes
Wireless LAN features
Wi-Fi: No
Ports & interfaces
Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Networking standards: IEEE 802.3at
Ethernet LAN (RJ-45) ports: 9
Power over Ethernet (PoE) ports quantity: 8
Supported network protocols: TCP,UDP,IPv4,IPv6,Http,Https,SMTP,NTP,SNTP
Power over Ethernet (PoE): Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Audio RCA inputs: 1
HDMI output: Yes
Audio RCA outputs: 1
VGA (D-Sub) output ports: 1
Logistics data
Products per master (outer) case: 4 pc(s)
Master (outer) case height: 412 mm
Master (outer) case length: 450 mm
Master (outer) case gross weight: 14.1 kg
Master (outer) case width: 548 mm
Hard drive
HDD interface: Serial ATA
Maximum storage capacity: 12 TB
HDD capacity: 0 GB
Number of HDDs supported: 2
