Design
Country of origin: China
Product colour: White
IK code: IK10
Protection features: Vandal proof
Mounting type: Ceiling
Weatherproof: Yes
International Protection (IP) code: IP66
Form factor: Dome
Power
Power source type: PoE
Power consumption (typical): 3.5 W
Power over Ethernet (PoE): Yes
Security
Active tampering alarm: Yes
IP address filtering: Yes
Video motion detection: Yes
Motion sensor: Yes
HTTPS encryption: Yes
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Reset button: Yes
Weight & dimensions
Depth: 111 mm
Height: 82 mm
Weight: 500 g
Width: 111 mm
Network
Bluetooth: No
Number of users: 20 user(s)
Cabling technology: 10/100Base-T(X)
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Supported network protocols: IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE, UPnP, IGMP, SNMP, QoS
Wi-Fi: No
Networking standards: IEEE 802.3u, IEEE 802.3, IEEE 802.3af
Quality of Service (QoS) support: Yes
System requirements
Windows operating systems supported: Windows 7 Home Basic x64, Windows Vista Enterprise, Windows 7 Professional, Windows 7 Home Premium, Windows 7 Starter, Windows Vista Business, Windows Vista Ultimate, Windows 7 Ultimate x64, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows Vista Business x64, Windows XP Professional, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows 7 Home Basic, Windows 7 Ultimate, Windows XP Professional x64, Windows Vista Ultimate x64, Windows 7 Enterprise, Windows Vista Home Premium, Windows XP Home, Windows 7 Starter x64, Windows Vista Home Basic x64, Windows 7 Professional x64, Windows Vista Home Premium x64, Windows XP Home x64
Certification: CE, FCC, ONVIF
Performance
Connectivity technology: Wired
Day/night mode: Yes
PTZ control: Yes
Wide Dynamic Range (WDR): Yes
Placement supported: Indoor & outdoor
Type: IP security camera
Packaging data
Package height: 108 mm
Package weight: 500 g
Package depth: 134 mm
Package type: Box
Package width: 134 mm
Packaging content
Number of cameras: 1
Resource CD: Yes
Screws included: Yes
Storage
Built-in HDD: No
Maximum memory card size: 16 GB
Compatible memory cards: MicroSDHC, SD, MicroSD (TransFlash)
Card reader integrated: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Field of view (FOV) angle: 78°
Camera shutter speed: 1 - 1/10000 s
Minimum illumination: 0.001 lx
Logistics data
Master (outer) case width: 345 mm
Master (outer) case length: 288 mm
Harmonized System (HS) code: 85258900
Products per master (outer) case: 24 pc(s)
Master (outer) case height: 568 mm
Image sensor
Sensor type: CMOS
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Progressive scan: Yes
Video
Noise reduction: Yes
Video compression formats: H.264, M-JPEG
Supported video modes: 1080p
Privacy masking: Yes
Total megapixels: 2 MP
Back Light Compensation (BLC): Yes
Flip & mirror: Yes
Image quality adjustment: Saturation, Contrast, Sharpness, Brightness
Video formats supported: AVI
Video streaming: Yes
Portrait mode: Yes
Time stamp overlay: Yes
Frame rate: 30 fps
Text caption overlay: Yes
Full HD: Yes
Supported graphics resolutions: 1920 x 1080 (HD 1080), 1280 x 1024 (SXGA)
Maximum resolution: 1920 x 1080 pixels
Night vision
Night vision: No
Lens system
Number of lenses: 1
Focus adjustment: 2.0
Fixed focal length: 6 mm
Sustainability
Compliance certificates: RoHS
