Design
Weatherproof: Yes
International Protection (IP) code: IP67
Country of origin: China
Form factor: Dome
IK code: IK10
Product colour: White
Mounting type: Ceiling
Power
Power consumption (Power over Ethernet (PoE)): 8 W
Power source type: DC, PoE
Power over Ethernet (PoE): Yes
Security
Intelligent Video Surveillance (IVS) system features: Crossing line, Region entrance detection, Region exiting detection, Defocus, Intrusion, Face detection
Video motion detection: Yes
Anti-flicker: Yes
Password protection: Yes
Digital watermark: Yes
Mirror: Yes
IP address filtering: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -30 - 60 °C
Management features
Reset button: Yes
Weight & dimensions
Height: 153.4 mm
Depth: 153.4 mm
Width: 133.1 mm
Weight: 1.29 kg
Network
Live view: Yes
Number of simultaneous live view channels: 20 channels
Wi-Fi: No
Supported network protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS,RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP,SNMP,IGMP,802.1X, QoS, IPv6, Bonjour
Ethernet LAN: Yes
Bluetooth: No
Certification: CE/FCC/UL
Performance
Infrared (IR) cut-off filter: Yes
Dynamic range: 140 dB
Connectivity technology: Wired
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Placement supported: Indoor & outdoor
Alarm input/output: Yes
Packaging data
Package type: Box
Package height: 244 mm
Package width: 174 mm
Package weight: 1.71 kg
Package depth: 173 mm
Packaging content
Resource CD: Yes
Number of cameras: 1
Screws included: Yes
Audio
Voice codecs: G.722, G.711, G.726, MP2L2, G.722.1
Storage
Compatible memory cards: SD, SDHC, SDXC, MicroSD (TransFlash)
Card reader integrated: Yes
Maximum memory card size: 256 GB
Built-in HDD: No
Ports & interfaces
DC-in jack: Yes
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 1
Microphone in: Yes
Camera
White balance: Auto
Lens viewing angle, horizontal: 103°
Lens viewing angle, diagonal: 124°
Lens viewing angle, vertical: 54°
Camera shutter speed: 1 - 1/100000 s
Other features
Browser supported: IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Logistics data
Master (outer) case height: 504 mm
Harmonized System (HS) code: 85258900
Master (outer) case length: 372 mm
Master (outer) case gross weight: 13.7 kg
Master (outer) case width: 365 mm
Products per master (outer) case: 8 pc(s)
Image sensor
Progressive scan: Yes
Sensor type: CMOS
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Video
Gain control type: Auto
Privacy masking: Yes
Image quality adjustment: Saturation, Sharpness, Brightness, Contrast
Back Light Compensation (BLC): Yes
Bit rate: 32Kbps~16Mbps
Video formats supported: H.265, M-JPEG, H.264
Supported graphics resolutions: 1280 x 960, 1920 x 1080 (HD 1080), 1280 x 720 (HD 720)
Maximum resolution: 1920 x 1080 pixels
Noise reduction: Yes
Noise reduction technology: 3D noise reduction
Total megapixels: 2 MP
Frame rate: 60 fps
Night vision
Night vision: Yes
LED type: IR
Night vision distance: 150 m
Lens system
Optical zoom: 4.3x
Zoom capability: Yes
