Design
International Protection (IP) code: IP67
IK code: IK10
Protection features: Rain proof, Dust resistant, Snow resistant, Vandal proof, Heat resistant
Mounting type: Ceiling/wall
Weatherproof: Yes
Country of origin: China
Form factor: Dome
Product colour: White
LED indicators: Power
Power
Power consumption (Power over Ethernet (PoE)): 7 W
Power source type: DC, PoE
Power consumption (max): 5 W
Power consumption: 400 mA
Security
Heartbeat: Yes
Video motion detection: Yes
Mirror: Yes
Active tampering alarm: Yes
Password protection: Yes
Anti-flicker: Yes
Digital watermark: Yes
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Reset button: Yes
Weight & dimensions
Diameter: 11.1 cm
Depth: 82 mm
Weight: 500 g
Network
Wi-Fi: No
Ethernet interface type: Fast Ethernet
Number of users: 32 user(s)
Ethernet LAN: Yes
Supported network protocols: TCP(IPv6/v4), UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, ICMP, ARP, IGMP,SMTP,FTP,SAMBA UPnP, SNMP, Bonjour
Bluetooth: No
Networking standards: IEEE 802.3u, IEEE 802.3, IEEE 802.1x, IEEE 802.3af
System requirements
Windows operating systems supported: Windows 7 Ultimate x64, Windows 7 x64, Windows 10, Windows 10 IOT Core, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 7 Professional, Windows 7, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 10 Pro x64, Windows 8 Enterprise, Windows 10 Education, Windows 10 Enterprise x64, Windows 10 x64, Windows 7 Professional x64, Windows 7 Home Basic, Windows 7 Ultimate, Windows 10 Home, Windows 7 Starter x64, Windows 10 Home x64, Windows 8, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 10 Education x64, Windows 8 Pro x64, Windows 8 x64
Mobile operating systems supported: iOS, Android
Certification: CE, FCC
Performance
Day/night mode: Yes
Infrared (IR) cut-off filter: Yes
Placement supported: Indoor & outdoor
Connectivity technology: Wired
Type: IP security camera
Packaging data
Package depth: 111 mm
Package height: 108 mm
Package weight: 502 g
Package type: Box
Package width: 134 mm
Packaging content
Number of cameras: 1
Screws included: Yes
Resource CD: Yes
Storage
Card reader integrated: Yes
Compatible memory cards: MicroSDHC, MicroSDXC
Built-in HDD: No
Ports & interfaces
Microphone in: Yes
Headphone outputs: 1
Terminal block port: Yes
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, vertical: 46°
Lens viewing angle, diagonal: 102°
Camera shutter speed: 1/3 - 1/100000 s
Minimum illumination: 0 lx
Field of view (FOV) angle: 86°
Other features
Browser supported: IIE7+, Chrome18-42, Firefox5.0+, Safari5.02+
Logistics data
Master (outer) case length: 111 mm
Master (outer) case gross weight: 608 g
Harmonized System (HS) code: 85258900
Master (outer) case width: 111 mm
Products per master (outer) case: 24 pc(s)
Master (outer) case height: 111 mm
Image sensor
Sensor type: CMOS
Progressive scan: Yes
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Video
Video formats supported: H.265, H.264, M-JPEG
Image quality adjustment: Saturation, Contrast, Sharpness, Brightness
Total megapixels: 2 MP
Back Light Compensation (BLC): Yes
Region of Interest (ROI) encoding: Yes
Noise reduction: Yes
Noise reduction technology: 3D noise reduction
Supported graphics resolutions: 640 x 480 (VGA), 1920 x 1080 (HD 1080), 1280 x 960, 320 x 240, 640 x 360, 1280 x 720 (HD 720)
Frame rate: 30 fps
Maximum resolution: 1920 x 1080 pixels
Privacy masking: Yes
Night vision
LED type: IR
Night vision distance: 30 m
Infra-red wavelength: 850 nm
Night vision: Yes
Lens system
Focus adjustment: 2.0
Number of lenses: 1
Digital zoom: 8x
Zoom capability: Yes
Fixed focal length: 4 mm
Sustainability
Compliance certificates: RoHS
