Design
Mounting type: Ceiling
Country of origin: China
International Protection (IP) code: IP67
Weatherproof: Yes
Form factor: Dome
Product colour: White
LED indicators: Power
Power
Power consumption (Power over Ethernet (PoE)): 9 W
DC output voltage: 12
Power source type: DC, PoE
Power consumption (max): 7.5 W
Security
Intelligent Video Surveillance (IVS) system features: Line crossing detection, Face detection, Human detection, Missing object, Vehicle detection, Intrusion
Video motion detection: Yes
Anti-flicker: Yes
Mirror: Yes
Heartbeat: Yes
Active tampering alarm: Yes
Password protection: Yes
Digital watermark: Yes
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
Height: 110 mm
Width: 82 mm
Depth: 110 mm
Weight: 500 g
Network
Ethernet interface type: Fast Ethernet
Supported network protocols: TCP(IPv6/v4), UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP,FTP,SAMBA UPnP, SNMP, Bonjour
Ethernet LAN: Yes
Wi-Fi: No
Networking standards: IEEE 802.3u, IEEE 802.3at, IEEE 802.3, IEEE 802.1x, IEEE 802.3af
Bluetooth: No
Performance
Infrared (IR) cut-off filter: Yes
Placement supported: Indoor & outdoor
Connectivity technology: Wired
Type: IP security camera
Packaging data
Package weight: 800 g
Package depth: 134 mm
Package width: 108 mm
Package height: 134 mm
Package type: Box
Packaging content
Number of cameras: 1
Screws included: Yes
Manual: Yes
Audio
Voice codecs: G.722.1, G.711, G.726, MP2L2, PCM
Signal-to-Noise Ratio (SNR): 52 dB
Audio system: 2-way
Storage
Built-in HDD: No
Compatible memory cards: MicroSDHC, MicroSDXC, MicroSD (TransFlash)
Maximum memory card size: 128 GB
Card reader integrated: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Terminal block port: Yes
Camera
Minimum illumination: 0 lx
Camera shutter speed: 1/3 - 1/100000 s
Lens viewing angle, vertical: 57°
Lens viewing angle, diagonal: 128°
Lens viewing angle, horizontal: 107°
Logistics data
Master (outer) case width: 568 mm
Harmonized System (HS) code: 852589
Master (outer) case height: 590 mm
Pallet gross width: 120 cm
Pallet gross height: 143 cm
Pallet gross length: 80 cm
Products per master (outer) case: 24 pc(s)
Master (outer) case gross weight: 21 kg
Master (outer) case length: 345 mm
Customs product code (TARIC): 8525890000
Image sensor
Optical sensor size: 25.4 / 2.4 mm (1 / 2.4")
Progressive scan: Yes
Sensor type: CMOS
Video
Privacy masking: Yes
Total megapixels: 6 MP
Video compression formats: M-JPEG, H.265, H.264
Supported graphics resolutions: 640 x 480 (VGA), 3200 x 1800, 640 x 360, 2688 x 1520, 1920 x 1080 (HD 1080), 1280 x 720 (HD 720), 2688 x 1512
Maximum resolution: 3200 x 1800 pixels
Night vision
Night vision: Yes
LED type: IR
Night vision distance: 30 m
Lens system
Zoom capability: Yes
Digital zoom: 8x
Fixed focal length: 2.8 mm
Number of lenses: 1
Maximum aperture number: 1.6
Sustainability
Compliance certificates: UKCA, CE, Federal Communications Commission (FCC)
