Design
Form factor: Bullet
Country of origin: China
International Protection (IP) code: IP67
Product colour: White
LED indicators: Power
Mounting type: Wall
Weatherproof: Yes
Power
Power consumption (max): 9 W
Power source type: PoE
AC input voltage: 12 V
Power over Ethernet (PoE): Yes
Power consumption (Power over Ethernet (PoE)): 7.5 W
Security
Human and vehicle targets classification: Yes
Intelligent Video Surveillance (IVS) system features: Intrusion, Face detection, Human detection, Crossing line, Vehicle detection, Region entrance detection, Region exiting detection
Active tampering alarm: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): -30 - 60 °C
Management features
Web-based management: Yes
Weight & dimensions
Weight: 1.08 kg
Width: 386 mm
Depth: 155 mm
Height: 156 mm
Network
Wi-Fi: No
Ethernet LAN: Yes
Quality of Service (QoS) support: Yes
Bluetooth: No
Live view: Yes
Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
Streaming method: Multicast
System requirements
Windows operating systems supported: Windows 10 Education, Windows 10, Windows 10 IOT Core, Windows 10 Enterprise x64, Windows 10 x64, Windows 10 Pro x64, Windows 10 Home x64, Windows 10 Home, Windows 10 Enterprise, Windows 10 Pro, Windows 10 IoT Enterprise, Windows 10 Education x64
Mac operating systems supported: Yes
Certification: FCC, UL
Performance
Type: IP security camera
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Placement supported: Indoor & outdoor
Infrared (IR) cut-off filter: Yes
Number of languages: 33
Dynamic range: 120 dB
Packaging data
Package width: 155 mm
Package weight: 1.4 kg
Package height: 380 mm
Package depth: 160 mm
Packaging content
Number of cameras: 1
Screws included: Yes
Manual: Yes
Resource CD: Yes
Audio
Audio system: 1-way
Storage
Compatible memory cards: MicroSDHC, MicroSDXC
Card reader integrated: Yes
Maximum memory card size: 256 GB
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Minimum illumination: 0 lx
Field of view (FOV) angle: 83.9°
Camera shutter speed: 1/3 - 1/100000 s
Other features
Browser supported: IE 10+, Chrome 57.0+, Firefox 52.0+
Logistics data
Master (outer) case gross weight: 15 kg
Pallet gross width: 120 cm
Products per master (outer) case: 9 pc(s)
Master (outer) case width: 490 mm
Master (outer) cases per pallet (air): 12 pc(s)
Pallet height (air): 12.6 m
Master (outer) case length: 400 mm
Master (outer) case height: 460 mm
Image sensor
Sensor type: CMOS
Video
Maximum resolution: 3200 x 1800 pixels
Supported graphics resolutions: 640 x 480 (VGA), 640 x 360, 2688 x 1520, 1920 x 1080 (HD 1080), 1280 x 720 (HD 720), 3200 x 1800
Video compression formats: H.265, H.264
Image quality adjustment: Sharpness, Brightness, Saturation, Contrast
Video formats supported: MPEG4
Total megapixels: 6 MP
Night vision
LED type: IR
Night vision distance: 60 m
Night vision: Yes
Lens system
Digital zoom: 8x
Sustainability
Sustainability compliance: Yes
Compliance certificates: RoHS, CE
