Design
Product colour: White, Black
International Protection (IP) code: IP66
Form factor: Dome
Country of origin: China
Mounting type: Ceiling
Weatherproof: Yes
LED indicators: Power
Power
Power source type: DC, PoE
DC output voltage: 12
Power over Ethernet (PoE): Yes
Power consumption (Power over Ethernet (PoE)): 20 W
Security
Heartbeat: Yes
Mirror: Yes
Password protection: Yes
IP address filtering: Yes
Anti-flicker: Yes
Digital watermark: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): -30 - 65 °C
Management features
Reset button: Yes
Web browser: Yes
Weight & dimensions
Width: 295 mm
Weight: 2 kg
Diameter: 16.4 cm
Network
Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
Ethernet interface type: Fast Ethernet
Quality of Service (QoS) support: Yes
Networking standards: IEEE 802.3at
Ethernet LAN: Yes
Cabling technology: 10/100Base-T(X)
Wi-Fi: No
Bluetooth: No
Number of users: 16 user(s)
System requirements
Windows operating systems supported: Windows 10, Windows 8, Windows 7
Certification: CE/FCC
Performance
PTZ control: Yes
Connectivity technology: Wired
Type: IP security camera
Infrared (IR) cut-off filter: Yes
Day/night mode: Yes
Placement supported: Indoor & outdoor
Packaging data
Package weight: 2.2 kg
Package width: 218 mm
Package depth: 384 mm
Package height: 218 mm
Package type: Box
Packaging content
Number of cameras: 1
Quick installation guide: Yes
Resource CD: Yes
Audio
Audio output channels: 1.0 channels
Audio input channels: 1.0 channels
Audio codecs: G.711/G.722/G.726/MP2L2
Storage
Compatible memory cards: SDXC, SDHC, SD
Built-in HDD: No
Card reader integrated: Yes
Maximum memory card size: 128 GB
Ports & interfaces
Interface: RJ-45
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
Camera
Camera shutter speed: 1 - 1/10000 s
Pan range: 0 - 360°
Minimum illumination: 0.01 lx
Auto flip: Yes
Pan speed: 80 °/sec
Tilt preset speed: 80 °/sec
Field of view (FOV) angle: 58.3°
Tilt angle range: -15 - 90°
Other features
Browser supported: Internet Explorer 9+
Data transfer rate: 16 Mbit/s
Logistics data
Pallet net width: 120 cm
Pallet net length: 80 cm
Harmonized System (HS) code: 85258900
Master (outer) case width: 460 mm
Master (outer) case gross weight: 9.5 kg
Master (outer) case height: 460 mm
Products per master (outer) case: 4 pc(s)
Pallet net height: 140 cm
Master (outer) case length: 405 mm
Image sensor
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Progressive scan: Yes
Sensor type: CMOS
Video
Digital Wide Dynamic Range (DWDR): Yes
Image quality adjustment: Brightness, Contrast, Sharpness, Saturation
Total megapixels: 2 MP
Video formats supported: AVI
Supported graphics resolutions: 1280 x 960, 1920 x 1080 (HD 1080), 1280 x 720 (HD 720)
Video compression formats: H.264, M-JPEG
Full HD: Yes
Privacy masking: Yes
Maximum resolution: 1920 x 1080 pixels
Frame rate: 60 fps
Night vision
Night vision distance: 50 m
LED type: IR
Night vision: Yes
Lens system
Number of lenses: 1
Minimum aperture number: 1.6
Maximum aperture number: 3.5
Focal length range: 4.7 - 94 mm
Optical zoom: 20x
