Design
Protection features: Weatherproof, Vandal proof
Form factor: Dome
International Protection (IP) code: IP67
Mounting type: Ceiling
Product colour: White
Country of origin: China
LED indicators: Activity, Power
Power
Power consumption (max): 10 W
Power source type: DC, PoE
Power consumption (Power over Ethernet (PoE)): 12 W
DC output voltage: 12
Security
Anti-flicker: Yes
Heartbeat: Yes
Digital watermark: Yes
Mirror: Yes
Intelligent Video Surveillance (IVS) system features: Line crossing detection, Missing object, Intrusion
Video motion detection: Yes
Password protection: Yes
Active tampering alarm: Yes
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
Width: 116 mm
Height: 153 mm
Depth: 153 mm
Weight: 800 g
Network
Wi-Fi: No
Ethernet LAN: Yes
Supported network protocols: TCP(IPv6/v4), UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP,FTP,SAMBA UPnP, SNMP, Bonjour
Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1x, IEEE 802.3af
Bluetooth: No
Performance
Dynamic range: 120 dB
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Placement supported: Indoor & outdoor
Infrared (IR) cut-off filter: Yes
Connectivity technology: Wired
Packaging data
Package width: 239 mm
Package weight: 1.3 kg
Package depth: 169 mm
Package height: 160 mm
Package type: Box
Packaging content
Number of cameras: 1
Screws included: Yes
Audio
Audio system: 1-way
Storage
Compatible memory cards: MicroSDHC, MicroSDXC, MicroSD (TransFlash)
Built-in HDD: No
Card reader integrated: Yes
Maximum memory card size: 256 GB
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, diagonal: 43 - 115°
Lens viewing angle, vertical: 21 - 52°
Lens viewing angle, horizontal: 38 - 98°
Camera shutter speed: 1/3 - 1/100000 s
Minimum illumination: 0 lx
Logistics data
Customs product code (TARIC): 8525890000
Products per master (outer) case: 12 pc(s)
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Master (outer) case width: 568 mm
Master (outer) case length: 345 mm
Harmonized System (HS) code: 852589
Master (outer) case height: 590 mm
Pallet gross height: 143 cm
Master (outer) case gross weight: 16 kg
Image sensor
Progressive scan: Yes
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Sensor type: CMOS
Video
Noise reduction: Yes
Total megapixels: 2 MP
Back Light Compensation (BLC): Yes
Noise reduction technology: 3D noise reduction
Frame rate: 30 fps
Image quality adjustment: Saturation, Contrast, Sharpness, Brightness
Video compression formats: M-JPEG, H.265, H.264
Privacy masking: Yes
Gain control type: Auto
Maximum resolution: 1920 x 1080 pixels
Supported graphics resolutions: 1920 x 1080 (HD 1080), 640 x 480 (VGA), 640 x 360, 1280 x 720 (HD 720)
Night vision
Night vision distance: 30 m
LED type: IR
Night vision: Yes
Lens system
Number of lenses: 1
Optical zoom: 4x
Zoom capability: Yes
Focal length range: 2.8 - 12 mm
Digital zoom: 16x
Maximum aperture number: 1.6
Sustainability
Compliance certificates: CE, UKCA, Federal Communications Commission (FCC)
