Design
International Protection (IP) code: IP67
Form factor: Bullet
Weatherproof: Yes
Mounting type: Wall
Country of origin: China
Product colour: White
LED indicators: Activity, Power
Power
Power consumption (Power over Ethernet (PoE)): 12.9 W
DC output voltage: 12
Power consumption (max): 11 W
Power source type: DC, PoE
Security
Active tampering alarm: Yes
Heartbeat: Yes
Anti-flicker: Yes
Video motion detection: Yes
Password protection: Yes
Mirror: Yes
Intelligent Video Surveillance (IVS) system features: Line crossing detection, Intrusion
IP address filtering: Yes
Digital watermark: Yes
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -30 - 60 °C
Weight & dimensions
Height: 252.5 mm
Width: 105 mm
Depth: 252.5 mm
Weight: 960 g
Network
Ethernet LAN: Yes
Wi-Fi: No
Bluetooth: No
Networking standards: IEEE 802.3at, IEEE 802.3af
Performance
Day/night mode: Yes
Wide Dynamic Range (WDR): Yes
Placement supported: Indoor & outdoor
Infrared (IR) cut-off filter: Yes
Type: IP security camera
Connectivity technology: Wired
Dynamic range: 120 dB
Packaging data
Package width: 280 mm
Package type: Box
Package height: 35 mm
Package weight: 1.4 kg
Package depth: 135 mm
Packaging content
Number of cameras: 1
Screws included: Yes
Manual: Yes
Audio
Signal-to-Noise Ratio (SNR): 52 dB
Audio system: 2-way
Storage
Compatible memory cards: MicroSDXC, MicroSDHC, MicroSD (TransFlash)
Built-in HDD: No
Card reader integrated: Yes
Maximum memory card size: 256 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Terminal block port: Yes
Camera
Lens viewing angle, diagonal: 38 - 134°
Camera shutter speed: 1/3 - 1/100000 s
Minimum illumination: 0 lx
Lens viewing angle, vertical: 18 - 58°
Lens viewing angle, horizontal: 33 - 110°
Logistics data
Customs product code (TARIC): 8525890000
Master (outer) case length: 550 mm
Master (outer) case width: 560 mm
Pallet gross height: 157 cm
Pallet gross width: 120 cm
Master (outer) case height: 610 mm
Products per master (outer) case: 9 pc(s)
Pallet gross length: 80 cm
Harmonized System (HS) code: 852589
Master (outer) case gross weight: 15 kg
Image sensor
Progressive scan: Yes
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS
Video
Video compression formats: H.265, H.264, M-JPEG
Highlight Compensation (HLC): Yes
Image quality adjustment: Saturation, Sharpness, Brightness, Contrast
Noise reduction technology: 3D noise reduction
Privacy masking: Yes
Gain control type: Auto
Total megapixels: 2 MP
Back Light Compensation (BLC): Yes
Noise reduction: Yes
Supported graphics resolutions: 1920 x 1080 (HD 1080), 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720)
Frame rate: 30 fps
Maximum resolution: 1920 x 1080 pixels
Night vision
LED type: IR
Night vision distance: 60 m
Night vision: Yes
Infra-red wavelength: 850 nm
Lens system
Optical zoom: 4.3x
Number of lenses: 1
Maximum aperture number: 1.6
Zoom capability: Yes
Digital zoom: 8x
Focal length range: 2.7 - 13.5 mm
Sustainability
Compliance certificates: CE, UKCA
