Design
Weatherproof: Yes
Mounting type: Floor/wall
Form factor: Bullet
IK code: IK10
International Protection (IP) code: IP66
Protection features: Vandal proof
Product colour: White
Country of origin: China
LED indicators: Activity, Link, Power
Power
Power consumption (Power over Ethernet (PoE)): 15 W
DC output voltage: 12
DC output current: 1.08 A
Power consumption (max): 13 W
Power source type: DC, PoE
Security
Human and vehicle targets classification: Yes
Mirror: Yes
Active tampering alarm: Yes
Intelligent Video Surveillance (IVS) system features: Intrusion, Crossing line, Face detection
Video motion detection: Yes
Operational conditions
Storage temperature (T-T): -30 - 70 °C
Operating temperature (T-T): -30 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
Height: 80 mm
Width: 100 mm
Depth: 300 mm
Weight: 1.89 kg
Network
Number of simultaneous live view channels: 3 channels
Wi-Fi: No
Ethernet LAN: Yes
Bluetooth: No
Networking standards: IEEE 802.3at
Performance
Infrared (IR) cut-off filter: No
Placement supported: Indoor & outdoor
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Connectivity technology: Wired
Packaging data
Package width: 190 mm
Package weight: 2.01 kg
Package type: Box
Package depth: 180 mm
Package height: 385 mm
Packaging content
Screws included: Yes
Number of cameras: 1
Audio
Voice codecs: PCM, G.722.1, MP2L2, G.711, G.726
Audio system: 2-way
Storage
Built-in HDD: No
Maximum memory card size: 256 GB
Compatible memory cards: MicroSDHC, MicroSDXC
Card reader integrated: Yes
Ports & interfaces
Terminal block port: Yes
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, horizontal: 32 - 106°
Lens viewing angle, diagonal: 37 - 127°
Lens viewing angle, vertical: 18 - 56°
Camera shutter speed: 1/3 - 1/100000 s
Minimum illumination: 0 lx
Logistics data
Pallet height (air): 168.8 cm
Pallet gross width: 120 cm
Master (outer) case height: 590 mm
Master (outer) cases per pallet (air): 12 pc(s)
Master (outer) case gross weight: 19 kg
Pallet gross length: 80 cm
Master (outer) case length: 405 mm
Master (outer) case width: 560 mm
Products per master (outer) case: 9 pc(s)
Harmonized System (HS) code: 8525890000
Image sensor
Progressive scan: Yes
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS
Video
Image quality adjustment: Contrast, Sharpness, Brightness, Saturation
Video compression formats: H.265, H.264, M-JPEG
Noise reduction: Yes
Noise reduction technology: 3D noise reduction
Privacy masking: Yes
Video streaming: Yes
Frame rate: 30 fps
Highlight Compensation (HLC): Yes
Back Light Compensation (BLC): Yes
Supported graphics resolutions: 640 x 360, 2688 x 1520, 3200 x 1800, 1280 x 720 (HD 720), 640 x 480 (VGA)
Total megapixels: 6 MP
Maximum resolution: 3200 x 1800 pixels
Night vision
Night vision: Yes
LED type: IR
Night vision distance: 60 m
Lens system
Optical zoom: 4.3x
Focal length range: 2.8 - 12 mm
Zoom capability: Yes
Sustainability
Compliance certificates: CE, Federal Communications Commission (FCC)
Sustainability compliance: Yes
