Design
Product colour: White
Country of origin: China
Mounting type: Ceiling
LED indicators: Activity, Power
IK code: IK10
Form factor: Dome
Protection features: Weatherproof, Vandal proof
International Protection (IP) code: IP66
Power
Power consumption (Power over Ethernet (PoE)): 12.5 W
Power source type: DC, PoE
DC output voltage: 12
Power consumption (max): 10.5 W
Security
Video motion detection: Yes
Intelligent Video Surveillance (IVS) system features: Scene change, Missing object, Region exiting detection, Human detection, Vehicle detection, Region entrance detection, Line crossing detection, Intrusion
Anti-flicker: Yes
Heartbeat: Yes
Mirror: Yes
Password protection: Yes
Active tampering alarm: Yes
Digital watermark: Yes
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -30 - 60 °C
Weight & dimensions
Weight: 1.1 kg
Width: 133.1 mm
Depth: 153.5 mm
Height: 153.5 mm
Network
Bluetooth: No
Networking standards: IEEE 802.3af, IEEE 802.3, IEEE 802.3u, IEEE 802.1x
Wi-Fi: No
Ethernet LAN: Yes
Supported network protocols: TCP(IPv6/v4), UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP,FTP,SAMBA UPnP, SNMP, Bonjour
Performance
Infrared (IR) cut-off filter: Yes
Type: CCTV security camera
Placement supported: Indoor & outdoor
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Packaging data
Package type: Box
Package weight: 1.7 kg
Package width: 244 mm
Package depth: 174 mm
Package height: 173 mm
Packaging content
Number of cameras: 1
Screws included: Yes
Manual: Yes
Audio
Audio system: 2-way
Storage
Compatible memory cards: MicroSDXC, MicroSDHC, MicroSD (TransFlash)
Built-in HDD: No
Card reader integrated: Yes
Maximum memory card size: 512 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Terminal block port: Yes
Camera
Lens viewing angle, diagonal: 41 - 127°
Lens viewing angle, horizontal: 35 - 106°
Lens viewing angle, vertical: 20 - 56°
Minimum illumination: 0 lx
Camera shutter speed: 1/3 - 1/100000 s
Logistics data
Harmonized System (HS) code: 852589
Customs product code (TARIC): 8525890000
Master (outer) case gross weight: 13 kg
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Master (outer) case height: 546 mm
Pallet gross height: 143 cm
Master (outer) case width: 610 mm
Master (outer) case length: 440 mm
Products per master (outer) case: 8 pc(s)
Image sensor
Sensor type: CMOS
Progressive scan: Yes
Optical sensor size: 25.4 / 2.4 mm (1 / 2.4")
Video
Video compression formats: H.264, H.265, M-JPEG
Maximum resolution: 3200 x 1800 pixels
Privacy masking: Yes
Image quality adjustment: Sharpness, Brightness, Saturation, Contrast
Noise reduction technology: 3D noise reduction
Supported graphics resolutions: 1920 x 1080 (HD 1080), 640 x 360, 640 x 480 (VGA), 2688 x 1520, 3200 x 1800, 1280 x 720 (HD 720)
Gain control type: Auto
Noise reduction: Yes
Back Light Compensation (BLC): Yes
Total megapixels: 6 MP
Frame rate: 30 fps
Night vision
Infra-red wavelength: 850 nm
Night vision: Yes
Night vision distance: 40 m
LED type: IR
Lens system
Number of lenses: 1
Optical zoom: 4.3x
Focal length range: 2.8 - 12 mm
Digital zoom: 8x
Sustainability
Compliance certificates: CE, Federal Communications Commission (FCC), UKCA
