Design
Product colour: White
Country of origin: China
Form factor: Dome
International Protection (IP) code: IP67
IK code: IK10
Mounting type: Ceiling
LED indicators: Power
Weatherproof: Yes
Power
Power source type: DC, PoE
Power consumption (max): 12.9 W
DC output voltage: 12
Power consumption (typical): 11.5 W
Security
Security algorithms: EAP-LEAP, HTTPS, TLS, EAP-MD5, EAP-TLS
Intelligent Video Surveillance (IVS) system features: Crossing line, Scene change, Intrusion, Abandoned object, Face detection, Missing object
Video motion detection: Yes
Password protection: Yes
IP address filtering: Yes
Alert notification type: E-mail, Snapshot alert message, Text alert message
Active tampering alarm: Yes
Digital watermark: Yes
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): 0 - 95 °C
Management features
Web-based management: Yes
Weight & dimensions
Weight: 1.29 kg
Height: 153.4 mm
Width: 133.1 mm
Depth: 153.4 mm
Network
Quality of Service (QoS) support: Yes
Networking standards: IEEE 802.3af
Bluetooth: No
Wi-Fi: No
Ethernet LAN: Yes
Performance
Type: IP security camera
Placement supported: Indoor & outdoor
Connectivity technology: Wired
Infrared (IR) cut-off filter: Yes
Packaging data
Package weight: 1.42 kg
Package type: Box
Package depth: 173 mm
Package height: 244 mm
Package width: 174 mm
Packaging content
Screws included: Yes
Number of cameras: 1
Audio
Voice codecs: G.711u, G.722.1, MP2L2, G.711a, G.726
Audio system: 2-way
Storage
Compatible memory cards: MicroSDHC, MicroSDXC
Built-in HDD: No
Card reader integrated: Yes
Maximum memory card size: 128 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Terminal block port: Yes
Camera
Lens viewing angle, diagonal: 38.5 - 146°
Lens viewing angle, vertical: 19 - 60°
Lens viewing angle, horizontal: 35 - 115°
Camera shutter speed: 1/3 - 1/100000 s
Logistics data
Harmonized System (HS) code: 8525890000
Pallet gross length: 80 cm
Products per master (outer) case: 12 pc(s)
Pallet gross width: 120 cm
Master (outer) cases per pallet (air): 18 pc(s)
Master (outer) case gross weight: 15 kg
Pallet height (air): 152 cm
Master (outer) case height: 504 mm
Master (outer) case length: 372 mm
Master (outer) case width: 365 mm
Image sensor
Progressive scan: Yes
Sensor type: CMOS
Optical sensor size: 25.4 / 2.5 mm (1 / 2.5")
Video
Supported graphics resolutions: 2944 x 1656, 1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160, 1280 x 720 (HD 720)
Maximum resolution: 3840 x 2160 pixels
Video compression formats: H.265, H.264
Digital Wide Dynamic Range (DWDR): Yes
Total megapixels: 8 MP
Image quality adjustment: Saturation, Brightness, Sharpness, Contrast
Night vision
Night vision: Yes
Night vision distance: 30 m
Lens system
Focal length range: 2.8 - 12 mm
Optical zoom: 4.3x
Maximum aperture number: 2
Zoom capability: Yes
Sustainability
Sustainability compliance: Yes
