Technical details
Iris: Yes
Design
Country of origin: China
Form factor: Bullet
International Protection (IP) code: IP66
Product colour: White
Mounting type: Ceiling/wall
Power
Power consumption (max): 7.5 W
Power source type: PoE
Power over Ethernet (PoE): Yes
Power consumption (typical): 5.5 W
DC output voltage: 12
Security
Video motion detection: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): 30 - 60 °C
Management features
Reset button: Yes
Cable management: Yes
Weight & dimensions
Weight: 1.2 kg
Depth: 258.6 mm
Height: 95 mm
Width: 105 mm
Network
Ethernet interface type: Fast Ethernet
Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3af
Ethernet LAN: Yes
Wi-Fi: No
Bluetooth: No
Streaming method: Multicast
Number of users: 20 user(s)
Supported network protocols: IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE, UPnP, IGMP, SNMP, QoS,Unicast
System requirements
Windows operating systems supported: Windows 8 x64, Windows 10 Education, Windows 10 Home x64, Windows 8, Windows 10, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows 7 Professional, Windows 7, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 10 Pro x64, Windows 8 Enterprise, Windows 7 Home Basic, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 10 Home, Windows 7 Starter x64, Windows 7 Professional x64, Windows 10 Enterprise x64, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 8 Pro x64, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 10 Education x64
Certification: CE,FCC
Performance
Type: IP security camera
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Infrared (IR) cut-off filter: Yes
Placement supported: Indoor & outdoor
Packaging data
Package width: 386 mm
Package weight: 1.33 kg
Package height: 155 mm
Package type: Box
Package depth: 156 mm
Packaging content
Number of cameras: 1
Resource CD: Yes
Audio
Voice codecs: G.722.1, G.711, G.726
Storage
Compatible memory cards: SDHC, SD, SDXC
Card reader integrated: Yes
Maximum memory card size: 128 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Terminal block port: Yes
Composite video out: 1
Camera
Camera shutter speed: 1/3 - 1/10000 s
Field of view (FOV) angle: 106°
Minimum illumination: 0 lx
Logistics data
Master (outer) case width: 490 mm
Master (outer) case height: 500 mm
Master (outer) case length: 400 mm
Harmonized System (HS) code: 85258900
Products per master (outer) case: 9 pc(s)
Master (outer) case gross weight: 11.9 kg
Image sensor
Progressive scan: Yes
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS
Video
Supported graphics resolutions: 1920 x 1080 (HD 1080), 1280 x 960, 1280 x 720 (HD 720)
Maximum resolution: 1920 x 1080 pixels
Portrait mode: Yes
Image quality adjustment: Contrast, Sharpness, Brightness, Saturation
Time stamp overlay: Yes
Video streaming: Yes
Frame rate: 30 fps
Text caption overlay: Yes
Noise reduction: Yes
Video formats supported: MP4
Total megapixels: 2 MP
Video compression formats: M-JPEG, H.264+, H.264
Privacy masking: Yes
Flip & mirror: Yes
Back Light Compensation (BLC): Yes
Night vision
Night vision distance: 30 m
LED type: IR
Night vision: Yes
Lens system
Number of lenses: 1
Zoom capability: Yes
Focus adjustment: 1.4
Optical zoom: 4x
Focal length range: 2.8 - 12 mm
Focus: Motorized
