Design
Stackable: No
Rack mounting: No
Product colour: Black
LED indicators: PoE, Power, Link
Power
Power source: DC
DC input voltage: 52 V
Power supply included: Yes
Power consumption (typical): 2 W
Input current: 1.25 A
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Depth: 78 mm
Width: 131 mm
Height: 28 mm
Weight: 320 g
Network
10G support: Yes
Full duplex: Yes
Flow control support: Yes
MAC address auto-aging supported: Yes
Copper ethernet cabling technology: 10BASE-T, 1000BASE-T, 100BASE-TX
MAC address auto-learning supported: Yes
Networking standards: IEEE 802.3u, IEEE 802.3at, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3ae, IEEE 802.3x
Ethernet LAN data rates: 2500,10000 Mbit/s
Performance
Fanless: Yes
Mean time between failures (MTBF): 300000 h
Packaging data
Package type: Box
Packaging content
Cables included: AC
Manual: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), CE
Ports & interfaces
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports quantity: 5
SFP+ module slots quantity: 1
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity: 5
Data transmission
MAC address table: 15000 entries
Packet buffer memory: 8 MB
Forwarding rate: 44 Mpps
Switching capacity: 35 Gbit/s
Jumbo frames: 15000
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 4
Total Power over Ethernet (PoE) budget: 65 W
Power over Ethernet (PoE): Yes
