Design
Rack mounting: Yes
Housing material: Metal
LED indicators: Power, Link, PoE
Product colour: Grey
Reset button: Yes
Power
Power consumption (max): 435 W
Input current: 6.5 A
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Security
DHCP features: DHCP snooping
IGMP snooping: Yes
SSH/SSL support: Yes
Authentication: Guest VLAN, Web-based authentication
Security algorithms: SNMPv3
DoS attack prevention: Yes
Password protection: Yes
Access Control List (ACL): Yes
IGMP proxy: Yes
Queue scheduling algorithms: Weighted Round Robin (WRR), Priority queuing (PQ)
Authentication type: RADIUS
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 45 °C
Storage relative humidity (H-H): 5 - 90%
Management features
Switch layer: L2
Quality of Service (QoS) support: Yes
Switch type: Managed
ARP inspection: Yes
Weight & dimensions
Width: 440 mm
Depth: 208 mm
Weight: 3.87 kg
Height: 44 mm
Network
Virtual LAN features: MAC address-based VLAN, Port-based VLAN, Tagged VLAN, Voice VLAN, VLAN Identifier ( VLAN ID), Protocol-based VLAN
Rate limiting: Yes
Link aggregation: Yes
Spanning tree protocol: Yes
10G support: No
Port mirroring: Yes
VLAN support: Yes
Broadcast storm control: Yes
Number of VLANs: 4000
QinQ implementation: Selective QinQ
Network virtualization technologies: Q-in-Q tunneling
Networking standards: IEEE 802.1D, IEEE 802.3z, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3az, IEEE 802.1v, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.1p, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3x
Performance
Internal memory: 8 MB
Telnet: Yes
Firmware upgradeable: Yes
Packaging data
Package weight: 4.2 kg
Package height: 88 mm
Package type: Box
Package depth: 295 mm
Resource CD: Yes
Package width: 555 mm
Rubber feet: Yes
Packaging content
Quick start guide: Yes
Rack mount kit: Yes
Cables included: AC
Certification: CE
Certificates
Compliance certificates: RoHS
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
IPv4 & IPv6 features: IPv6 Telnet
Ports & interfaces
Console port: RJ-45
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Gigabit Ethernet (copper) ports quantity: 24
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: China
Data transmission
Forwarding rate: 38.69 Mpps
Packet buffer memory: 128 MB
MAC address table: 8000 entries
Jumbo frames support: Yes
Store-and-forward: Yes
Jumbo frames: 9000
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 24
Total Power over Ethernet (PoE) budget: 370 W
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: v1/v2
