Design
Form factor: 1U
Rack mounting: Yes
Stackable: No
Product colour: Black
LED indicators: Activity, Speed, System, PoE, Link
Power
Power source: AC
Power supply included: Yes
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Security
BPDU filtering/protection: Yes
Password protection: Yes
Access Control List (ACL): Yes
Operational conditions
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 85 °C
Operating temperature (T-T): -10 - 50 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Switch layer: L2
Quality of Service (QoS) support: Yes
Switch type: Managed
Weight & dimensions
Width: 442 mm
Weight: 4 kg
Height: 44 mm
Depth: 285 mm
Network
Networking standards: IEEE 802.3at, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3af, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p
10G support: No
Port mirroring: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
VLAN support: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Broadcast storm control: Yes
Performance
Firmware upgradeable: Yes
Fanless: No
Packaging data
Package width: 395 mm
Package depth: 90 mm
Package height: 530 mm
Package type: Box
Package weight: 4.8 kg
Packaging content
Rack mount kit: Yes
Cables included: AC
Quick start guide: Yes
Ports & interfaces
Console port: RJ-45
Basic switching RJ-45 Ethernet ports quantity: 24
SFP module slots quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power connector: AC-in jack
Gigabit Ethernet (copper) ports quantity: 24
Logistics data
Country of origin: China
Harmonized System (HS) code: 85176990
Data transmission
MAC address table: 16000 entries
Switching capacity: 56 Gbit/s
Jumbo frames: 10000
Jumbo frames support: Yes
Packet buffer memory: 4 MB
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 390 W
Power over Ethernet (PoE) power per port: 30 W
Multicast features
Multicast support: Yes
