Features Plug and Play: Yes Product colour: Black Internal: No LED indicators: Yes Housing material: Metal
Power Output voltage: 12 - 24 V Power over Ethernet (PoE): Yes Power consumption (typical): 4.5 W
Operational conditions Storage temperature (T-T): -40 - 75 °C Operating relative humidity (H-H): 10 - 90% Storage relative humidity (H-H): 0 - 95% Operating temperature (T-T): -20 - 65 °C
Weight & dimensions Height: 23 mm Weight: 220 g Width: 94.5 mm Depth: 72.5 mm
Network Ethernet LAN data rates: 100, 10, 1000 Mbit/s Ethernet interface type: Gigabit Ethernet, Fast Ethernet Maximum data transfer rate: 1000 Mbit/s Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z
Performance Maximum transfer distance: 3000 m
Packaging data Package depth: 132 mm Package weight: 350 g Package type: Box Package height: 92 mm Package width: 143 mm
Logistics data Master (outer) case gross weight: 11.7 kg Pallet gross height: 149 cm Pallet gross width: 120 cm Master (outer) case width: 434 mm Master (outer) case length: 307 mm Harmonized System (HS) code: 8517620000 Pallet gross length: 100 cm Master (outer) case height: 482 mm Products per master (outer) case: 30 pc(s) Country of origin: Taiwan Customs product code (TARIC): 8517620000
