Design
LED indicators: Activity, Link, Power
Product colour: Black
Enclosure material: Metal
Power
Input voltage: 100 - 240 V
Input frequency: 50/60 Hz
Operational conditions
Operating temperature (T-T): -20 - 55 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 95%
Management features
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 294 mm
Weight: 1.4 kg
Height: 44 mm
Depth: 189 mm
Network
Networking standards: IEEE 802.3u, IEEE 802.3, IEEE 802.3ab
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
Cabling technology: 10/100/1000Base-T(X)
Performance
Control display unit: No
Flash memory: 16 MB
Internal memory: 256 MB
Packaging data
Package width: 325 mm
Package height: 81 mm
Package type: Box
Package weight: 2.08 kg
Package depth: 241 mm
Packaging content
Quick start guide: Yes
Cables included: AC
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE
Ports & interfaces
Ethernet LAN (RJ-45) ports: 4
WAN connection: Ethernet (RJ-45)
Logistics data
Country of origin: China
Sustainability
Sustainability compliance: Yes
