Design
Product colour: Black
LED indicators: Activity, Link, Power
Enclosure material: Metal
Power
Input frequency: 50/60 Hz
Input voltage: 100 - 240 V
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): -20 - 55 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 90%
Management features
Quality of Service (QoS) support: Yes
Weight & dimensions
Depth: 221 mm
Height: 44 mm
Weight: 2.1 kg
Width: 440 mm
Network
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Cabling technology: 10/100/1000Base-T(X)
Performance
Internal memory: 512 MB
Control display unit: No
Flash memory: 16 MB
Packaging data
Package depth: 285 mm
Package weight: 2.98 kg
Package width: 500 mm
Package height: 80 mm
Package type: Box
Packaging content
Cables included: AC
Quick start guide: Yes
Certificates
Compliance certificates: RoHS, CE, Federal Communications Commission (FCC)
Ports & interfaces
WAN connection: Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports: 4
Logistics data
Country of origin: China
Sustainability
Sustainability compliance: Yes
