Design
Internal: Yes
LED indicators: Activity, Link
Operational conditions
Operating temperature (T-T): 0 - 55 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Height: 115 mm
Depth: 68 mm
Width: 17 mm
Weight: 67 g
Network
Auto-negotiation: Yes
VLAN tagging: Yes
Full duplex: Yes
Jumbo frames: 9000
Jumbo frames support: Yes
Fiber ethernet cabling technology: 1000BASE‑SX
Maximum data transfer rate: 1000 Mbit/s
Networking standards: IEEE 802.3, IEEE 802.1p, IEEE 802.3ad, IEEE 802.1Q, IEEE 802.3x
Wake-on-LAN ready: Yes
System requirements
Other operating systems supported: DOS, Novell NetWare 5.x, Novell NetWare 6.x
Windows operating systems supported: Windows 7 Enterprise x64, Windows 7 Professional, Windows XP Home, Windows 7 Starter x64, Windows 7 Home Basic x64, Windows Vista Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 7 Home Premium, Windows 7 Professional x64, Windows 7 Starter, Windows Vista Ultimate x64, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows 7 Home Basic, Windows 7 Ultimate, Windows 2000, Windows XP Professional x64, Windows XP Professional, Windows Vista Home Premium x64, Windows XP Home x64, Windows 8 x64, Windows 8 Pro x64, Windows Vista Home Basic x64, Windows Vista Enterprise, Windows Vista Home Premium, Windows Vista Enterprise x64, Windows Vista Business, Windows Vista Home Basic, Windows Vista Business x64
Server operating systems supported: Windows Server 2012 R2 x64, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2012 R2, Windows Server 2008, Windows Server 2003, Windows Server 2008 x64, Windows Server 2003 x64
Linux operating systems supported: Yes
Packaging data
Package depth: 30 mm
Package height: 230 mm
Drivers included: Yes
Package width: 153 mm
Package weight: 86 g
Packaging content
Mounting brackets included: Yes
Manual: Yes
Ports & interfaces
Fiber optic connector: SC
Host interface: PCI Express
Fiber ports quantity: 1
Interface: Fiber
Connectivity technology: Wired
Other features
Flow control support: Yes
Quick start guide: Yes
Logistics data
Harmonized System (HS) code: 85176990
