Design
Product colour: Grey
Reset button: Yes
Rack mounting: Yes
Safety: FCC Part 15 Subpart B
Housing material: Metal
LED indicators: Activity, System, Link, Power
Power
AC input frequency: 50 - 60 Hz
Power consumption (max): 50 W
Redundant power supply (RPS) support: Yes
AC input voltage: 100 - 240 V
Security
IGMP proxy: Yes
Authentication type: AAA, RADIUS
IP-MAC-Port binding: Yes
Queue scheduling algorithms: Deficit Round Robin (DRR), Weighted Round Robin (WRR)
DoS attack prevention: Yes
IGMP snooping: Yes
DHCP features: DHCP server, DHCP client
Authentication: Guest VLAN
Password protection: Yes
Access Control List (ACL): Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 90 °C
Operating temperature (T-T): 0 - 50 °C
Heat dissipation: 170.65 BTU/h
Management features
Web-based management: Yes
ARP inspection: Yes
Configuring Location Settings (CLI): Yes
Quality of Service (QoS) support: Yes
System event log: Yes
Switch layer: L3
Switch type: Managed
Weight & dimensions
Depth: 315 mm
Weight: 3.6 kg
Width: 440 mm
Height: 44 mm
Network
Networking standards: IEEE 802.3, IEEE 802.3ah, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3az, IEEE 802.1p, IEEE 802.1ab, IEEE 802.1x, IEEE 802.1w
Ethernet LAN data rates: 10,100,1000 Mbit/s
Policy-based routing: Yes
VLAN support: Yes
Network virtualization technologies: Q-in-Q tunneling
Head-of-line (HOL) blocking: Yes
IP routing: Yes
Fast leave: Yes
Port mirroring: Yes
Link aggregation: Yes
Virtual LAN features: Port-based VLAN, Multicast VLAN, Voice VLAN, MAC address-based VLAN, Private VLAN
Full duplex: Yes
Spanning tree protocol: Yes
Broadcast storm control: Yes
Flow control support: Yes
10G support: Yes
Performance
Maximum data transfer rate: 10000 Mbit/s
Internal memory: 512 MB
Telnet: Yes
Flash memory: 16 MB
Dying Gasp: Yes
Mean time between failures (MTBF): 185680 h
Packaging data
Rubber feet: Yes
Package width: 576 mm
Package depth: 448 mm
Package weight: 5.3 kg
Package height: 94 mm
Package type: Box
Resource CD: Yes
Packaging content
Quick start guide: Yes
Cables included: AC
Rack mount kit: Yes
Certification: CE
Certificates
Compliance certificates: RoHS
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Console port: RJ-45
Basic switching RJ-45 Ethernet ports quantity: 8
Power connector: AC-in jack
SFP+ module slots quantity: 12
Other features
Ethernet LAN: Yes
Logistics data
Country of origin: China
Harmonized System (HS) code: 85176990
Data transmission
Packet forwarding rate (1 Gbps): 13690474 pps
Switching capacity: 256 Gbit/s
Packet forwarding rate (10 Mbps): 136904 pps
Packet forwarding rate (100 Mbps): 1369047 pps
Jumbo frames: 9000
Static route: Yes
Number of queues: 8
Number of IP interfaces: 256
MAC address table: 32000 entries
Packet buffer memory: 3 MB
Store-and-forward: Yes
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Number of multicast groups filtered: 256
Multicast support: Yes
