Design
LED indicators: Yes
Reset button: Yes
Product colour: Grey
Rack mounting: Yes
Housing material: Metal
Power
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (typical): 468.2 W
Input current: 6 A
Security
IGMP snooping: Yes
IGMP proxy: Yes
Authentication type: RADIUS
DHCP features: DHCP server, DHCP snooping, DHCP relay
Queue scheduling algorithms: Priority queuing (PQ), Weighted Round Robin (WRR)
Access Control List (ACL): Yes
Authentication: MAC-based authentication
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 45 °C
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Management features
Web-based management: Yes
ARP inspection: Yes
Traffic classification: Yes
Configuring Location Settings (CLI): Yes
Quality of Service (QoS) support: Yes
System event log: Yes
Switch type: Managed
Switch layer: L3
Weight & dimensions
Weight: 4.48 kg
Width: 330 mm
Height: 44.5 mm
Depth: 440 mm
Network
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.3, IEEE 802.1p, IEEE 802.3at, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1x, IEEE 802.1D, IEEE 802.3z, IEEE 802.1w, IEEE 802.3af, IEEE 802.3az, IEEE 802.1v, IEEE 802.3ad, IEEE 802.1s
Ethernet LAN data rates: 10,100,1000 Mbit/s
10G support: Yes
Link aggregation: Yes
Spanning tree protocol: Yes
Full duplex: Yes
Broadcast storm control: Yes
Rate limiting: Yes
Port mirroring: Yes
Performance
Firmware upgradeable: Yes
Plug and Play: Yes
Virtual stacking (units): 4
Flash memory: 32 MB
Internal memory: 512 MB
Mean time between failures (MTBF): 150000 h
Packaging data
Package width: 390 mm
Rubber feet: Yes
Resource CD: Yes
Package height: 80 mm
Package depth: 596 mm
Package weight: 6 kg
Packaging content
Quick start guide: Yes
Cables included: AC
Rack mount kit: Yes
Certification: CE
Certificates
Compliance certificates: RoHS
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Fiber ports quantity: 4
Power connector: AC-in jack
Fiber optic connector: SFP+
Gigabit Ethernet (copper) ports quantity: 24
Basic switching RJ-45 Ethernet ports quantity: 24
SFP+ module slots quantity: 4
Logistics data
Country of origin: China
Harmonized System (HS) code: 85176990
Data transmission
Jumbo frames support: Yes
MAC address table: 16000 entries
Packet buffer memory: 1.5 MB
Maximum data transfer rate: 10 Gbit/s
Jumbo frames: 12000
Store-and-forward: Yes
Forwarding rate: 95.232 Mpps
Switching capacity: 128 Gbit/s
Static route: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 400 W
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
