Features
Housing material: Metal
Internal: No
LED indicators: Activity, Link, Power
Product colour: Black
Hot-swap: Yes
Power
Input voltage: 5 V
Input current: 3 A
Power consumption (typical): 1.2 W
Operational conditions
Operating relative humidity (H-H): 5 - 90%
Operating temperature (T-T): -10 - 55 °C
Storage temperature (T-T): -40 - 75 °C
Weight & dimensions
Depth: 85 mm
Weight: 300 g
Height: 25 mm
Width: 115 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3an
Maximum data transfer rate: 10000 Mbit/s
Auto MDI/MDI-X: Yes
Copper ethernet cabling technology: 10GBASE-T, 1000BASE-SX, 10BASE-T, 100BASE-TX, 1000BASE-LX, 1000BASE-T
Ethernet interface type: Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Ethernet LAN data rates: 10, 10000 Mbit/s, 1000 Mbit/s, 100
Duplex system: Full
Cable types supported: Cat6a
Fiber ethernet cabling technology: 10GBASE-LR, 10GBASE-SR, 10GBASE-ER, 10GBASE-ZR
Jumbo frames: 9000
Jumbo frames support: Yes
Performance
Maximum transfer distance: 100 m
Mean time between failures (MTBF): 50000 h
Packaging data
Package height: 85 mm
Package width: 230 mm
Package weight: 700 g
Package depth: 150 mm
Package type: Box
Packaging content
AC adapter included: Yes
Quick installation guide: Yes
Certification: CE
Certificates
Compliance certificates: RoHS
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Connectivity technology: Wired
Fiber optic connector: SFP
Logistics data
Country of origin: China
Harmonized System (HS) code: 85176990
