Features Audio system: Multichannel HDCP: Yes Audio output channels: 7.1 channels 3D: Yes Maximum resolution: 3840 x 2160 pixels Type: AV transmitter Product colour: Black Plug and Play: Yes Consumer Electronics Control (CEC) support: Yes Cable types supported: Cat5e, Cat6 HDCP & EDID bypass: Yes Supported video modes: 1080p, 720p Bandwidth: 10.2 Gbit/s Maximum transfer distance: 100 m Colour depth: 36 bit Material: Metal Carrier frequency: 38 kHz Baud rate: 115.2 Kbit/s
Power Current: 6.6 A Operating voltage: 12 V Power consumption (transmitter) (max): 5000 mA
Weight & dimensions Weight: 1.27 kg Height: 44 mm Depth: 160 mm Width: 300 mm Transmitter dimensions (WxDxH): 300 x 160 x 44 mm Transmitter weight: 1.22 kg
Packaging data Package dimensions (WxDxH): 280 x 160 x 120 mm Package weight: 2.2 kg Package width: 280 mm Package type: Box Package depth: 160 mm Package height: 120 mm
Packaging content AC adapter included: Yes Manual: Yes Cables included: AC Remote control included: Yes
Ports & interfaces DC-in jack: Yes Number of HDMI outputs: 1 RS-232 input ports: 1 HDMI in: 1 3.5 mm (1/8-inch) in: Yes RJ-45 output ports: 4 3.5 mm (1/8-inch) out: Yes
