Features Audio output channels: 7.1 channels Audio system: Multichannel Networking standards: IEEE 802.3af Type: AV transmitter HDCP: Yes LED indicators: Link, Power, PoE Maximum resolution: 3840 x 2160 pixels 3D: Yes HDCP & EDID bypass: Yes Carrier frequency: 38 kHz Consumer Electronics Control (CEC) support: Yes Baud rate: 115.2 Kbit/s Cable types supported: Cat6, Cat5e Supported video modes: 1080p Material: Metal Colour depth: 36 bit Maximum transfer distance: 100 m Plug and Play: Yes Bandwidth: 10.2 Gbit/s
Power Power over Ethernet (PoE): Yes Power consumption (transmitter) (max): 5000 mA Operating voltage: 12 V Current: 6.6 A
Weight & dimensions Weight: 380 g Transmitter weight: 1.27 kg Depth: 160 mm Width: 300 mm Transmitter dimensions (WxDxH): 300 x 160 x 44 mm Height: 44 mm
Packaging data Package weight: 2.25 kg Package dimensions (WxDxH): 280 x 160 x 120 mm Package type: Box Package width: 280 mm Package depth: 160 mm Package height: 120 mm
Packaging content AC adapter included: Yes Manual: Yes Remote control included: Yes Cables included: AC
Ports & interfaces DC-in jack: Yes RJ-45 output ports: 4 RS-232 input ports: 1 3.5 mm (1/8-inch) in: Yes HDMI in: 1 3.5 mm (1/8-inch) out: Yes Number of HDMI outputs: 1
