Design
Product colour: Black
LED indicators: Activity, Power, Link
Rack mounting: Yes
Stackable: No
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power source: AC
Power supply included: Yes
Power consumption (typical): 6 W
Security
IGMP snooping: Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -40 - 70 °C
Heat dissipation: 20.4 BTU/h
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2
Switch type: Managed
Weight & dimensions
Weight: 720 g
Height: 44.5 mm
Depth: 150 mm
Width: 215 mm
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3z, IEEE 802.3u, IEEE 802.3az
Full duplex: Yes
Port mirroring: Yes
VLAN support: Yes
Half duplex: Yes
Auto MDI/MDI-X: Yes
Broadcast storm control: Yes
10G support: No
Number of VLANs: 32
Auto-negotiation: Yes
MAC address auto-learning supported: Yes
MAC address auto-aging supported: Yes
Link aggregation: Yes
Rate limiting: Yes
Performance
Noise level: 0 dB
Flash memory: 2 MB
Fanless: Yes
Packaging data
Package weight: 1.19 kg
Package width: 285 mm
Package type: Box
Package height: 62 mm
Package depth: 257 mm
Packaging content
Quick start guide: Yes
Cables included: AC
Rack mount kit: Yes
Ports & interfaces
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 8
Logistics data
Country of origin: China
Data transmission
Switching capacity: 16 Gbit/s
MAC address table: 4000 entries
Packet buffer memory: 1.5 MB
Jumbo frames: 9000
Jumbo frames support: Yes
Forwarding rate: 11.904 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
