Technical details
Pallet gross width: 120 cm
Master (outer) cases per pallet (air): 16 pc(s)
Pallet gross length: 80 cm
Pallet height (air): 174.4 cm
Design
Product colour: Black
Rack mounting: No
LED indicators: Link, Activity
Power
DC input voltage: 12 V
Power consumption (max): 10 W
Surge protection: Yes
Power source: DC
Power supply included: Yes
Surge protection voltage: 8 kV
Input current: 1 A
Security
IGMP snooping: Yes
Operational conditions
Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 95%
Heat dissipation: 34.12 BTU/h
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2
Switch type: Managed
Weight & dimensions
Weight: 700 g
Depth: 121 mm
Height: 35 mm
Width: 225 mm
Network
10G support: No
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3u, IEEE 802.3az, IEEE 802.3z
Number of VLANs: 32
Port mirroring: Yes
Flow control support: Yes
Rate limiting: Yes
Virtual LAN features: Tagged VLAN
Link aggregation: Yes
Broadcast storm control: Yes
Full duplex: Yes
MAC address auto-aging supported: Yes
VLAN support: Yes
MAC address auto-learning supported: Yes
Performance
Flash memory: 2 MB
Fanless: Yes
Noise level: 0 dB
Mean time between failures (MTBF): 43800 h
Packaging data
Package weight: 950 g
Package type: Box
AC adapter included: Yes
Package width: 290 mm
Package height: 93 mm
Package depth: 172 mm
Packaging content
Quick start guide: Yes
Certification: UKCA, FCC Class A
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
Combo SFP ports quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 8
Logistics data
Country of origin: China
Master (outer) case gross weight: 12.2 kg
Master (outer) case width: 540 mm
Master (outer) case length: 320 mm
Master (outer) case height: 400 mm
Master (outer) case net weight: 750 g
Products per master (outer) case: 12 pc(s)
Data transmission
MAC address table: 8000 entries
Packet buffer memory: 1.5 MB
Jumbo frames: 9000
Jumbo frames support: Yes
Switching capacity: 20 Gbit/s
Number of queues: 4
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Sustainability
Sustainability compliance: Yes
