Technical details
Layers per pallet (air): 16 pc(s)
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Design
Product colour: Black
DIN rail mounting: Yes
International Protection (IP) code: IP30
LED indicators: Activity, Power, Link
Power
DC input voltage: 44 - 57 V
Surge protection voltage: 4 kV
Redundant power supply (RPS) support: Yes
Surge protection: Yes
Power protection features: Surge protection
Power source: DC/PoE
Power supply included: No
Power consumption (typical): 120 W
Security
Queue scheduling algorithms: Priority queuing (PQ)
IGMP snooping: Yes
Operational conditions
Heat dissipation: 81.89 BTU/h
Operating temperature (T-T): -40 - 75 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 85 °C
Management features
Web-based management: Yes
Switch layer: L2
Switch type: Managed
Quality of Service (QoS) support: Yes
Weight & dimensions
Height: 50 mm
Width: 149.5 mm
Depth: 122.5 mm
Weight: 550 g
Network
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3af, IEEE 802.3u, IEEE 802.3at, IEEE 802.1D, IEEE 802.3z
MAC address auto-aging supported: Yes
Port mirroring: Yes
Auto-negotiation: Yes
Number of VLANs: 32
10G support: No
Flow control support: Yes
Link aggregation: Yes
Spanning tree protocol: Yes
Virtual LAN features: Port-based VLAN, Tagged VLAN
Half duplex: Yes
Broadcast storm control: Yes
MAC address auto-learning supported: Yes
Rate limiting: Yes
Full duplex: Yes
Auto MDI/MDI-X: Yes
Copper ethernet cabling technology: 100BASE-TX, 1000BASE-X, 10BASE-T, 1000BASE-T
VLAN support: Yes
Performance
Fanless: Yes
Flash memory: 2 MB
Noise level: 0 dB
Mean time between failures (MTBF): 43800 h
Packaging data
Terminal block included: Yes
DIN rail included: Yes
Package weight: 780 g
Package width: 230 mm
Package height: 73 mm
Package type: Box
Package depth: 160 mm
Packaging content
Quick start guide: Yes
Certificates
Compliance certificates: RoHS, CE, Federal Communications Commission (FCC), UKCA
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Fiber uplink ports quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 8
Gigabit Ethernet (copper) ports quantity: 8
SFP module slots quantity: 2
Logistics data
Country of origin: China
Master (outer) case width: 480 mm
Master (outer) case height: 350 mm
Master (outer) case length: 395 mm
Products per master (outer) case: 20 pc(s)
Pallet gross height: 154.4 cm
Master (outer) case gross weight: 16 kg
Harmonized System (HS) code: 8517620090
Data transmission
MAC address table: 4000 entries
Jumbo frames: 9000
Packet buffer memory: 1.5 MB
Forwarding rate: 14.88 Mpps
Jumbo frames support: Yes
Switching capacity: 20 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 8
Total Power over Ethernet (PoE) budget: 110 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
Sustainability
Sustainability compliance: Yes
