Technical details
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Pallet height (air): 159.4 cm
Master (outer) cases per pallet (air): 20 pc(s)
Design
LED indicators: System, Activity, PoE, Link, Power
Product colour: Black
Rack mounting: Yes
Power
Power consumption (max): 250 W
Power source: AC/PoE
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Surge protection: Yes
Surge protection voltage: 8 kV
Security
IGMP snooping: Yes
Operational conditions
Operating temperature (T-T): 0 - 45 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Heat dissipation: 81.89 BTU/h
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2
Switch type: Managed
Weight & dimensions
Width: 440 mm
Weight: 2.4 kg
Height: 44.5 mm
Depth: 190 mm
Network
Networking standards: IEEE 802.1Q, IEEE 802.3at, IEEE 802.1p, IEEE 802.3af, IEEE 802.3az
Full duplex: Yes
Copper ethernet cabling technology: 100BASE-TX, 1000BASE-T, 10BASE-T
VLAN support: Yes
Rate limiting: Yes
Broadcast storm control: Yes
Link aggregation: Yes
10G support: No
Flow control support: Yes
Number of VLANs: 32
Port mirroring: Yes
MAC address auto-learning supported: Yes
MAC address auto-aging supported: Yes
Virtual LAN features: Tagged VLAN
Performance
Noise level: 30 dB
Mean time between failures (MTBF): 43800 h
Flash memory: 2 MB
Fanless: No
Packaging data
Package type: Box
Package width: 503 mm
Package height: 85 mm
Package weight: 3 kg
Package depth: 270 mm
Packaging content
Quick start guide: Yes
Cables included: AC
Rack mount kit: Yes
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 16
SFP module slots quantity: 2
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 16
Logistics data
Country of origin: China
Master (outer) case gross weight: 12.8 kg
Products per master (outer) case: 4 pc(s)
Master (outer) case net weight: 750 g
Master (outer) case height: 290 mm
Master (outer) case width: 515 mm
Master (outer) case length: 360 mm
Data transmission
Jumbo frames support: Yes
Switching capacity: 36 Gbit/s
Jumbo frames: 9000
MAC address table: 8000 entries
Packet buffer memory: 4.1 MB
Number of queues: 4
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 230 W
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet plus (PoE+) ports quantity: 16
Multicast features
Multicast support: Yes
Sustainability
Sustainability compliance: Yes
