Technical details
Pallet height (air): 182.4 cm
Master (outer) cases per pallet (air): 12 pc(s)
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Design
Rack mounting: Yes
Product colour: Black
LED indicators: Power, Activity, Link
Power
Surge protection voltage: 8 kV
Surge protection: Yes
Power source: AC
AC input frequency: 50 - 60 Hz
Power consumption (max): 15 W
AC input voltage: 100 - 240 V
Security
IGMP snooping: Yes
Operational conditions
Heat dissipation: 51.18 BTU/h
Operating temperature (T-T): 0 - 45 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Management features
Switch layer: L2
Switch type: Managed
Web-based management: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Height: 44.5 mm
Weight: 1.08 kg
Depth: 181.5 mm
Width: 271 mm
Network
Virtual LAN features: Tagged VLAN
Rate limiting: Yes
Broadcast storm control: Yes
Port mirroring: Yes
MAC address auto-learning supported: Yes
Link aggregation: Yes
MAC address auto-aging supported: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.3az, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3x
VLAN support: Yes
10G support: No
Number of VLANs: 32
Performance
Fanless: Yes
Noise level: 0 dB
Flash memory: 2 MB
Mean time between failures (MTBF): 43800 h
Packaging data
Package width: 350 mm
Package weight: 1.68 kg
Package type: Box
Package height: 89 mm
Package depth: 267 mm
Packaging content
Rack mount kit: Yes
Cables included: AC
Quick start guide: Yes
Certification: UKCA, FCC Class A
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 16
Logistics data
Master (outer) case height: 560 mm
Master (outer) case net weight: 1 kg
Master (outer) case length: 370 mm
Master (outer) case width: 480 mm
Products per master (outer) case: 10 pc(s)
Country of origin: China
Master (outer) case gross weight: 17.8 kg
Data transmission
Jumbo frames: 9000
Number of queues: 4
Jumbo frames support: Yes
Switching capacity: 36 Gbit/s
MAC address table: 8000 entries
Packet buffer memory: 4.1 MB
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Sustainability
Sustainability compliance: Yes
