Technical details
Master (outer) cases per pallet (air): 16 pc(s)
Pallet gross length: 80 cm
Pallet height (air): 174.4 cm
Pallet gross width: 120 cm
Design
Product colour: Black
Rack mounting: Yes
LED indicators: Link, PoE, Activity, Power, System
Power
Power source: AC/PoE
Surge protection: Yes
Power consumption (max): 400 W
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Surge protection voltage: 8 kV
Security
IGMP snooping: Yes
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 45 °C
Heat dissipation: 88.71 BTU/h
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2
Switch type: Managed
Weight & dimensions
Weight: 3.4 kg
Height: 44.5 mm
Width: 440 mm
Depth: 290 mm
Network
VLAN support: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
Networking standards: IEEE 802.3at, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3az, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3u, IEEE 802.3z
10G support: No
Number of VLANs: 32
Full duplex: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Rate limiting: Yes
Virtual LAN features: Tagged VLAN
MAC address auto-aging supported: Yes
MAC address auto-learning supported: Yes
Port mirroring: Yes
Performance
Flash memory: 2 MB
Noise level: 30 dB
Fanless: No
Mean time between failures (MTBF): 43800 h
Packaging data
Package width: 515 mm
Package height: 93 mm
Package type: Box
Package depth: 380 mm
Package weight: 4.1 kg
Packaging content
Rack mount kit: Yes
Cables included: AC
Quick start guide: Yes
Certification: UKCA, FCC Class A
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity: 4
Gigabit Ethernet (copper) ports quantity: 24
Logistics data
Products per master (outer) case: 3 pc(s)
Master (outer) case gross weight: 13.1 kg
Country of origin: China
Master (outer) case length: 320 mm
Master (outer) case net weight: 750 g
Master (outer) case width: 540 mm
Master (outer) case height: 400 mm
Data transmission
Switching capacity: 56 Gbit/s
Jumbo frames: 9000
Jumbo frames support: Yes
MAC address table: 8000 entries
Packet buffer memory: 4.1 MB
Number of queues: 4
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 24
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 380 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
