Technical details
Pallet height (air): 159.4 cm
Pallet gross length: 80 cm
Pallet gross width: 120 cm
Master (outer) cases per pallet (air): 20 pc(s)
Design
LED indicators: System, Link, Activity, Power
Rack mounting: Yes
Product colour: Black
Power
Power consumption (max): 20 W
AC input voltage: 100 - 240 V
Power source: AC
AC input frequency: 50 - 60 Hz
Surge protection: Yes
Surge protection voltage: 8 kV
Security
IGMP snooping: Yes
Operational conditions
Operating temperature (T-T): 0 - 45 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Heat dissipation: 68.24 BTU/h
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2
Switch type: Managed
Weight & dimensions
Weight: 1.95 kg
Height: 44.5 mm
Depth: 190 mm
Width: 440 mm
Network
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.3z, IEEE 802.3u, IEEE 802.3az, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p
Full duplex: Yes
VLAN support: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring: Yes
Link aggregation: Yes
10G support: No
Number of VLANs: 32
Rate limiting: Yes
MAC address auto-aging supported: Yes
Virtual LAN features: Tagged VLAN
Broadcast storm control: Yes
Flow control support: Yes
MAC address auto-learning supported: Yes
Performance
Flash memory: 2 MB
Noise level: 0 dB
Fanless: Yes
Mean time between failures (MTBF): 43800 h
Packaging data
Package type: Box
Package height: 85 mm
Package weight: 2.55 kg
Package width: 503 mm
Package depth: 270 mm
Packaging content
Quick start guide: Yes
Cables included: AC
Rack mount kit: Yes
Certification: UKCA, FCC Class A
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
Combo SFP ports quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 24
Gigabit Ethernet (copper) ports quantity: 24
Logistics data
Country of origin: China
Master (outer) case net weight: 750 g
Products per master (outer) case: 4 pc(s)
Master (outer) case height: 290 mm
Master (outer) case width: 515 mm
Master (outer) case length: 360 mm
Master (outer) case gross weight: 10.9 kg
Data transmission
MAC address table: 8000 entries
Jumbo frames: 9000
Switching capacity: 56 Gbit/s
Packet buffer memory: 4.1 MB
Number of queues: 4
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Sustainability
Sustainability compliance: Yes
