Technical details
Layers per pallet (air): 16 pc(s)
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Design
Rack mounting: Yes
International Protection (IP) code: IP30
Product colour: Black
LED indicators: Link, Activity, Power
Power
Power source: DC
Surge protection: Yes
Power protection features: Surge protection
Redundant power supply (RPS) support: Yes
Power supply included: No
Power consumption (typical): 20 W
DC input voltage: 12 - 57 V
Surge protection voltage: 4 kV
Security
IGMP snooping: Yes
Queue scheduling algorithms: Priority queuing (PQ)
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 85 °C
Storage relative humidity (H-H): 5 - 95%
Heat dissipation: 68.24 BTU/h
Management features
Quality of Service (QoS) support: Yes
Switch type: Managed
Switch layer: L2
Web-based management: Yes
Weight & dimensions
Depth: 244 mm
Width: 440 mm
Height: 45 mm
Weight: 3.4 kg
Network
Full duplex: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-X, 1000BASE-T
VLAN support: Yes
Number of VLANs: 32
10G support: No
Port mirroring: Yes
MAC address auto-aging supported: Yes
Rate limiting: Yes
Virtual LAN features: Tagged VLAN, Port-based VLAN
MAC address auto-learning supported: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Flow control support: Yes
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.3az, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.3z
Performance
Flash memory: 2 MB
Noise level: 0 dB
Mean time between failures (MTBF): 43800 h
Fanless: Yes
Packaging data
Package height: 93 mm
Package width: 510 mm
Package depth: 375 mm
Terminal block included: Yes
Package weight: 4 kg
Package type: Box
Packaging content
Rack mount kit: Yes
Quick start guide: Yes
Certificates
Compliance certificates: RoHS, CE, UKCA, Federal Communications Commission (FCC)
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 28
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity: 4
Gigabit Ethernet (copper) ports quantity: 24
Logistics data
Pallet gross height: 174.4 cm
Master (outer) case length: 320 mm
Harmonized System (HS) code: 8517620090
Products per master (outer) case: 3 pc(s)
Master (outer) case gross weight: 12.5 kg
Master (outer) case width: 540 mm
Master (outer) case height: 400 mm
Country of origin: China
Data transmission
Switching capacity: 56 Gbit/s
MAC address table: 8000 entries
Packet buffer memory: 4.1 MB
Jumbo frames support: Yes
Jumbo frames: 9000
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Sustainability
Sustainability compliance: Yes
