Technical details
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Master (outer) cases per pallet (air): 18 pc(s)
Pallet height (air): 158.4 cm
Design
LED indicators: Yes
Product colour: Black
Power
Surge protection: Yes
Input voltage: 54 V
Power supply included: Yes
Power source: DC/PoE
Input current: 1.2 A
Power consumption (max): 65 W
Surge protection voltage: 8 kV
Security
IGMP snooping: Yes
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 95%
Heat dissipation: 23.88 BTU/h
Operating temperature (T-T): 0 - 45 °C
Management features
Switch layer: L2
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch type: Managed
Weight & dimensions
Width: 160 mm
Weight: 400 g
Height: 29 mm
Depth: 95 mm
Network
Half duplex: Yes
Port mirroring: Yes
Auto MDI/MDI-X: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
VLAN support: Yes
Networking standards: IEEE 802.3at, IEEE 802.3x, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az
Full duplex: Yes
Number of VLANs: 32
10G support: No
Flow control support: Yes
Virtual LAN features: Tagged VLAN
MAC address auto-aging supported: Yes
Rate limiting: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Auto-negotiation: Yes
MAC address auto-learning supported: Yes
Performance
Flash memory: 2 MB
Noise level: 0 dB
Mean time between failures (MTBF): 43800 h
Packaging data
Package type: Box
Package height: 65 mm
Package depth: 230 mm
Package weight: 920 g
AC adapter included: Yes
Package width: 310 mm
Packaging content
Quick start guide: Yes
Cables included: AC
Certification: UKCA, FCC Class A
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Logistics data
Master (outer) case height: 480 mm
Country of origin: China
Master (outer) case gross weight: 9.8 kg
Master (outer) case length: 330 mm
Products per master (outer) case: 10 pc(s)
Master (outer) case width: 350 mm
Master (outer) case net weight: 600 g
Data transmission
MAC address table: 2000 entries
Packet buffer memory: 1.5 MB
Jumbo frames support: Yes
Switching capacity: 10 Gbit/s
Jumbo frames: 9000
Number of queues: 4
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 60 W
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 4
Multicast features
Multicast support: Yes
Sustainability
Sustainability compliance: Yes
