Technical details
Pallet gross width: 120 cm
Layers per pallet (air): 16 pc(s)
Pallet gross length: 80 cm
Design
International Protection (IP) code: IP30
Redundant fans support: Yes
Product colour: Black
DIN rail mounting: Yes
LED indicators: Activity, Power, Link
Power
DC input voltage: 44 - 57 V
Power protection features: Surge protection
Power source: DC/PoE
Surge protection: Yes
Redundant power supply (RPS) support: Yes
Surge protection voltage: 4 kV
Power supply included: No
Power consumption (typical): 68 W
Security
IGMP snooping: Yes
Queue scheduling algorithms: Priority queuing (PQ)
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 85 °C
Heat dissipation: 27.3 BTU/h
Management features
Switch layer: L2
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch type: Managed
Weight & dimensions
Depth: 108 mm
Width: 136 mm
Height: 38.5 mm
Weight: 450 g
Network
MAC address auto-aging supported: Yes
Virtual LAN features: Port-based VLAN, Tagged VLAN
Rate limiting: Yes
Auto MDI/MDI-X: Yes
Spanning tree protocol: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1w, IEEE 802.3z, IEEE 802.3af, IEEE 802.3az, IEEE 802.3at
Port mirroring: Yes
Auto-negotiation: Yes
Link aggregation: Yes
Broadcast storm control: Yes
VLAN support: Yes
Copper ethernet cabling technology: 1000BASE-X, 100BASE-TX, 10BASE-T, 1000BASE-T
10G support: No
Number of VLANs: 32
Full duplex: Yes
Flow control support: Yes
Half duplex: Yes
MAC address auto-learning supported: Yes
Performance
Noise level: 0 dB
Flash memory: 2 MB
Fanless: Yes
Mean time between failures (MTBF): 43800 h
Packaging data
Package type: Box
Package width: 191 mm
Package height: 60 mm
Terminal block included: Yes
Package weight: 680 g
Package depth: 135 mm
DIN rail included: Yes
Packaging content
Quick start guide: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE, UKCA
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 4
Basic switching RJ-45 Ethernet ports quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Fiber uplink ports quantity: 2
SFP module slots quantity: 2
Logistics data
Master (outer) case width: 480 mm
Master (outer) case length: 395 mm
Products per master (outer) case: 34 pc(s)
Harmonized System (HS) code: 8517620090
Pallet gross height: 154.4 cm
Master (outer) case height: 350 mm
Country of origin: China
Master (outer) case gross weight: 24 kg
Data transmission
Packet buffer memory: 1.5 MB
Jumbo frames: 9000
MAC address table: 2000 entries
Jumbo frames support: Yes
Switching capacity: 12 Gbit/s
Forwarding rate: 8.928 Mpps
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 68 W
Power over Ethernet plus (PoE+) ports quantity: 4
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
Sustainability
Sustainability compliance: Yes
