Technical details
Pallet gross length: 80 cm
Pallet gross width: 120 cm
Pallet height (air): 158.4 cm
Master (outer) cases per pallet (air): 18 pc(s)
Design
Rack mounting: No
LED indicators: PoE, Activity, Link
Product colour: Black
Power
Power source: DC/PoE
Power supply included: Yes
Power consumption (max): 120 W
Surge protection: Yes
Input current: 2.2 A
DC input voltage: 54 V
Surge protection voltage: 8 kV
Security
IGMP snooping: Yes
Operational conditions
Operating temperature (T-T): 0 - 45 °C
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 27.3 BTU/h
Management features
Quality of Service (QoS) support: Yes
Switch layer: L2
Web-based management: Yes
Switch type: Managed
Weight & dimensions
Width: 160 mm
Depth: 95 mm
Weight: 400 g
Height: 29 mm
Network
Full duplex: Yes
VLAN support: Yes
Half duplex: Yes
Number of VLANs: 32
Auto MDI/MDI-X: Yes
Virtual LAN features: Tagged VLAN
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.3af, IEEE 802.3az, IEEE 802.3at, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u
MAC address auto-aging supported: Yes
Rate limiting: Yes
Flow control support: Yes
Port mirroring: Yes
Auto-negotiation: Yes
Link aggregation: Yes
Broadcast storm control: Yes
MAC address auto-learning supported: Yes
Performance
Flash memory: 2 MB
Noise level: 0 dB
Mean time between failures (MTBF): 43800 h
Fanless: Yes
Packaging data
Package weight: 1.3 kg
AC adapter included: Yes
Package height: 65 mm
Package depth: 230 mm
Package width: 310 mm
Package type: Box
Packaging content
Cables included: AC
Certification: UKCA, FCC Class A
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
Gigabit Ethernet (copper) ports quantity: 8
Logistics data
Master (outer) case length: 330 mm
Products per master (outer) case: 10 pc(s)
Master (outer) case height: 480 mm
Master (outer) case gross weight: 13.6 kg
Master (outer) case width: 350 mm
Master (outer) case net weight: 600 g
Country of origin: China
Data transmission
MAC address table: 4000 entries
Jumbo frames support: Yes
Switching capacity: 16 Gbit/s
Packet buffer memory: 1.5 MB
Number of queues: 4
Jumbo frames: 9000
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 112.8 W
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 8
Multicast features
Multicast support: Yes
Sustainability
Sustainability compliance: Yes
