Technical details
Pallet height (air): 170.4 cm
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Master (outer) cases per pallet (air): 16 pc(s)
Design
Rack mounting: No
Product colour: Black
LED indicators: Power, Link
Power
Power consumption (max): 6 W
Power source: DC
Surge protection: Yes
DC input voltage: 12 V
Power supply included: Yes
Surge protection voltage: 8 kV
Input current: 1 A
Security
IGMP snooping: Yes
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 45 °C
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 20.4 BTU/h
Management features
Quality of Service (QoS) support: Yes
Switch layer: L2
Switch type: Managed
Web-based management: Yes
Weight & dimensions
Width: 160 mm
Depth: 95 mm
Height: 29 mm
Weight: 350 g
Network
Virtual LAN features: Tagged VLAN
MAC address auto-aging supported: Yes
Rate limiting: Yes
Link aggregation: Yes
Half duplex: Yes
VLAN support: Yes
Auto MDI/MDI-X: Yes
Broadcast storm control: Yes
Full duplex: Yes
Auto-negotiation: Yes
MAC address auto-learning supported: Yes
Port mirroring: Yes
10G support: No
Number of VLANs: 32
Flow control support: Yes
Networking standards: IEEE 802.3az, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u
Performance
Noise level: 0 dB
Flash memory: 2 MB
Fanless: Yes
Mean time between failures (MTBF): 43800 h
Packaging data
Package width: 264 mm
Package height: 52 mm
Package type: Box
AC adapter included: Yes
Package weight: 500 g
Package depth: 122 mm
Packaging content
Quick start guide: Yes
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
Gigabit Ethernet (copper) ports quantity: 8
Logistics data
Master (outer) case length: 330 mm
Products per master (outer) case: 36 pc(s)
Master (outer) case width: 550 mm
Master (outer) case height: 390 mm
Master (outer) case net weight: 700 g
Master (outer) case gross weight: 18.7 kg
Country of origin: China
Data transmission
Jumbo frames support: Yes
Packet buffer memory: 1.5 MB
Switching capacity: 16 Gbit/s
MAC address table: 4000 entries
Number of queues: 4
Jumbo frames: 9000
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Sustainability
Sustainability compliance: Yes
