Technical details
Pallet gross width: 120 cm
Pallet gross length: 80 cm
Layers per pallet (air): 16 pc(s)
Design
International Protection (IP) code: IP30
DIN rail mounting: Yes
Product colour: Black
LED indicators: Link, Activity, Power
Power
Redundant power supply (RPS) support: Yes
DC input voltage: 12 - 57 V
Power protection features: Surge protection
Power source: DC
Surge protection: Yes
Surge protection voltage: 4 kV
Power supply included: No
Power consumption (typical): 6 W
Security
Queue scheduling algorithms: Priority queuing (PQ)
IGMP snooping: Yes
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 20.47 BTU/h
Management features
Quality of Service (QoS) support: Yes
Switch layer: L2
Switch type: Managed
Web-based management: Yes
Weight & dimensions
Depth: 114 mm
Height: 38 mm
Weight: 530 g
Width: 153 mm
Network
Virtual LAN features: Tagged VLAN, Port-based VLAN
Port mirroring: Yes
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Rate limiting: Yes
Full duplex: Yes
MAC address auto-aging supported: Yes
Spanning tree protocol: Yes
Broadcast storm control: Yes
Link aggregation: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
VLAN support: Yes
10G support: No
Number of VLANs: 32
Flow control support: Yes
MAC address auto-learning supported: Yes
Networking standards: IEEE 802.1D, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1w, IEEE 802.3az, IEEE 802.3u
Half duplex: Yes
Performance
Noise level: 0 dB
Fanless: Yes
Flash memory: 2 MB
Mean time between failures (MTBF): 43800 h
Packaging data
DIN rail included: Yes
Package depth: 160 mm
Package width: 230 mm
Package weight: 780 g
Terminal block included: Yes
Package type: Box
Package height: 73 mm
Packaging content
Quick start guide: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE, UKCA
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
Gigabit Ethernet (copper) ports quantity: 8
Logistics data
Master (outer) case length: 395 mm
Master (outer) case width: 480 mm
Master (outer) case height: 350 mm
Products per master (outer) case: 20 pc(s)
Pallet gross height: 154.4 cm
Harmonized System (HS) code: 8517620090
Master (outer) case gross weight: 16 kg
Country of origin: China
Data transmission
MAC address table: 4000 entries
Packet buffer memory: 1.5 MB
Jumbo frames support: Yes
Switching capacity: 16 Gbit/s
Forwarding rate: 11.904 Mpps
Jumbo frames: 9000
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Sustainability
Sustainability compliance: Yes
