Features Country of origin: Taiwan Product colour: Black LED indicators: Yes
Power Output voltage: 12 V Power consumption (typical): 22 W
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 10 - 85%
Weight & dimensions Weight: 1.39 kg Package type: Box Depth: 245 mm Package width: 380 mm Width: 135 mm Height: 115 mm Package weight: 980 g Package depth: 195 mm Package height: 170 mm
System requirements Browser supported: Microsoft Internet Explorer 9/10/11 Windows operating systems supported: Yes Minimum RAM: 4 GB Mobile operating systems supported: Android, iOS Minimum processor speed: 2.66 GHz Minimum processor: Intel Core 2 Quad
Performance Video loss detection: Yes Snapshot: Yes PTZ control: Yes Video formats supported: H.264 Throughput data rate: 36 Mbit/s Audio formats supported: PCM, G.711 Playback modes: Forward, Pause, Reverse, Stop Operating system installed: Embedded LINUX Languages support: Multi Video input channels: 9 channels Number of simultaneous viewers: 3 Video motion detection: Yes Number of users: 3 user(s) Maximum frame rate: 30 fps
Packaging content Quick installation guide: Yes Cables included: AC CD manual: Yes
Wireless LAN features Wi-Fi: No
Ports & interfaces DC-in jack: Yes Ethernet LAN (RJ-45) ports: 2 USB 2.0 ports quantity: 2 HDMI output: Yes
Logistics data Products per master (outer) case: 4 pc(s) Master (outer) case gross weight: 10.6 kg Master (outer) case width: 410 mm Master (outer) case height: 380 mm Master (outer) case length: 295 mm
Hard drive HDD interface: Serial ATA HDD size: 3.5" HDD capacity: 0 GB Total installed storage capacity: 0 GB Maximum storage capacity: 8 TB Number of HDDs supported: 2
