Design
Rack mounting: No
LED indicators: PoE, Power, Link, Activity
Product colour: Black
DIN rail mounting: Yes
Power
Power source: DC
Power consumption (max): 380 W
Power consumption (typical): 5 W
DC input voltage: 48 - 57 V
Security
MAC address filtering: Yes
DHCP features: DHCP snooping, DHCP Option 82, DHCP client, DHCP relay
Password protection: Yes
BPDU filtering/protection: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -40 - 75 °C
Storage temperature (T-T): -40 - 85 °C
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2
ARP inspection: Yes
Switch type: Managed
Weight & dimensions
Depth: 115 mm
Width: 165 mm
Weight: 500 g
Height: 50 mm
Network
Networking standards: IEEE 802.3at, IEEE 802.3x, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bt, IEEE 802.3af
VLAN support: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
10G support: No
Virtual LAN features: Port-based VLAN, Voice VLAN, Tagged VLAN, MAC address-based VLAN, Private VLAN, Protocol-based VLAN
Spanning tree protocol: Yes
Flow control support: Yes
Port mirroring: Yes
Link aggregation: Yes
Auto-negotiation: Yes
Broadcast storm control: Yes
Performance
Noise level: 0 dB
Internal memory: 1024 MB
Flash memory: 128 MB
Mean time between failures (MTBF): 338634 h
Fanless: Yes
Packaging data
Package width: 270 mm
Package type: Box
Package height: 74 mm
Package weight: 1.13 kg
Package depth: 181 mm
Packaging content
Quick start guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity: 2
Console port: RJ-45
Gigabit Ethernet (copper) ports quantity: 8
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: China
Data transmission
MAC address table: 8000 entries
Jumbo frames support: Yes
Jumbo frames: 10000
Static route: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 10 W
Total Power over Ethernet (PoE) budget: 360 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
