Design
Product colour: Black
Safety: UL (UL60950-1)
Rack mounting: Yes
LED indicators: Link, Power, Diagnostic
Power
AC input frequency: 50 - 60 Hz
Input voltage: 48 - 60 V
Redundant power supply (RPS) support: Yes
Power consumption (typical): 21.48 W
AC input voltage: 100 - 240 V
Security
Packet filtering: CDP/PVST+
IGMP snooping: Yes
Static port security: Yes
Authentication: MAC-based authentication, Port-based authentication, Web-based authentication
Loop protection: Yes
Access Control List (ACL): Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 50 °C
Management features
ARP inspection: Yes
Quality of Service (QoS) support: Yes
Switch layer: L3
Switch type: Managed
Weight & dimensions
Width: 440 mm
Weight: 2.82 kg
Depth: 220 mm
Height: 44 mm
Network
Virtual LAN features: IP subnet–based VLAN, Port-based VLAN, MAC address-based VLAN, Protocol-based VLAN
Networking standards: IEEE 802.3ad, IEEE 802.1s, IEEE 802.3x, IEEE 802.1D, IEEE 802.3ah, IEEE 802.3z, IEEE 802.3ae, IEEE 802.1w, IEEE 802.1ag
Auto MDI/MDI-X: Yes
Full duplex: Yes
Auto-negotiation: Yes
VLAN support: Yes
Link aggregation: Yes
10G support: Yes
Performance
Telnet: Yes
Memory type: DRAM
Flash memory: 256 MB
Internal memory: 512 MB
Mean time between failures (MTBF): 298951 h
Packaging data
Package width: 580 mm
Package type: Box
Package height: 80 mm
Package weight: 3.77 kg
Package depth: 405 mm
Resource CD: Yes
Packaging content
Quick start guide: Yes
Cables included: AC
Rack mount kit: Yes
Protocols
IPv4 & IPv6 features: Dual stack IPv4/IPv6
GARP VLAN Registration Protocol (GVRP): Yes
Management protocols: CLI, WEB, TELNET
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: No
Console port: RJ-45
Fiber optic connector: SFP
Combo SFP ports quantity: 4
SFP module slots quantity: 20
SFP+ module slots quantity: 4
Logistics data
Country of origin: China
Harmonized System (HS) code: 85176990
Master (outer) case height: 340 mm
Master (outer) case width: 600 mm
Products per master (outer) case: 4 pc(s)
Master (outer) case length: 435 mm
Master (outer) case gross weight: 16.6 kg
Data transmission
Jumbo frames: 9000
Static route: Yes
Forwarding rate: 95 Mpps
Jumbo frames support: Yes
MAC address table: 16000 entries
Switching capacity: 128 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Optical fiber
Fiber ethernet cabling technology: 10GBASE-LR, 1000BASE‑LX, 1000BASE-SX, 1000BASE‑ZX, 10GBASE-ER, 1000BASE-LHX, 10GBASE-SR
